6 Ambient Conditions
In operation Transport Storage
Max. ambient
temperature
+0 ℃ to +50 ℃ -25 ℃ to +70 ℃
Humidity Min. relative humidity: 20
%
Max. relative humidity:
85 %
Condensation not allowed
Min. relative humidity: 20
%
Max. relative humidity:
75 %
Condensation not allowed
Min. relative humidity:
20 %
Max. relative humidity:
85 %
Condensation not allowed
Air pressure Up to 3000 m above sea level acc. to EN 61131-2
Mechanical
strength
Max. vibration:
Frequency range: 10 Hz to
150 Hz
Excursion: 0.075 mm at
10 Hz to 57 Hz
Acceleration: 1 g at 57 Hz
to 150 Hz
acc. to EN 600068-2-6
Max. shock:
15 g 11 ms
acc. to EN 60068-2-27,
no disturbance of the function
Contamination
level
2
Overvoltage
category
3 -
Tab. 6-1: Ambient conditions
7
Technical Data
7.1 VR 21 Singletouch
VR2104 Singletouch VR2107 Singletouch VR2109 Singletouch
Display 107.95 mm TFT (4.3")
480 × 272 pixels
65536 colors
Brightness 450 cd/m
2
Display
53,8 × 95 (H × B)
177.8 mm TFT (7")
800 × 480 pixels
262144 colors
Brightness 350 cd/m
2
Display
91.4 × 152.4 (H × B)
228.6 mm TFT (9")
800 × 480 pixels
16.77 million colors
Brightness 360 cd/m
2
Display
117 × 195 (H × B)
Touch technology Analog resistive, 4-wire technology
Touch activation pres-
sure
15 g (standard) with R8 HS60 silicone rubber
Housing Sheet steel, zinc-coated
Bosch Rexroth AG
Technical Data
VR 21
6/29
DOK-SUPPL*-VR21**.01**-IT02-EN-P
