Bosch Rexroth IndraControl VR 21 Series User Manual

VR2104 Singletouch VR2107 Singletouch VR2109 Singletouch
Front panel material Aluminium, brushed, naturally anodized
Enclosure rating Front panel IP 65 according to DIN EN 60 529, rear side IP 20
Central processing unit ARM Cortex™-A8, 800 MHz with real-time clock
Flash memory 256 MByte
LPDDR memory 512 MByte
Voltage supply DC 24 V (use a 24 V power supply unit according to DIN EN 60742, classifi-
cation VDE 0551, for example the power supply unit VAP01.1H-
W23-024-010-NN, part number R911171065)
Current consumption 0.2 A (typically at 24 V)
0.3 A (maximum)
0.3 A (typically at 24 V)
0.4 A (maximum)
0.6 A (typically at 24 V)
0.7 A (maximum)
Connection value 4.8 W 7.2 W 14.4 W
Fuse Semiconductor fuse, resettable
Reverse voltage protec-
tion
Integrated
USB Per USB port max. 500 mA, total current at all USB ports is max. 1 A.
Weight Approx. 0.6 kg Approx. 0.8 kg Approx. 1.3 kg
Tab. 7-1: Technical data of the VR 21 Singletouch
7.2 VR 21 Multitouch
VR2107 Multitouch VR2109 Multitouch
Display 177.8 mm TFT (7")
800 × 480 pixels
262144 colors
Brightness 350 cd/m
2
Display 91.4 × 152.4 (H × B)
228.6 mm TFT (9")
800 × 480 pixels
16.77 million colors
Brightness 360 cd/m
2
Display 117 × 195 (H × B)
Touch technology Projected capacitive, can be operated with finger
Touch activation pressure 15 g (standard) with R8 HS60 silicone rubber
Housing Sheet steel, zinc-coated
Front panel material Aluminium, brushed, naturally anodized
Surface of the front panel Glass
Enclosure rating Front panel IP 65 according to DIN EN 60 529
Rear panel IP 20
Central processing unit
ARM Cortex
TM
-A8, 800 MHz with real-time clock
Flash memory 256 MByte
LPDDR memory 512 MByte
VR 21 Bosch Rexroth AG
Technical Data
DOK-SUPPL*-VR21**.01**-IT02-EN-P
7/29
