2.5 Components Diagram
Fig. 1
A Heating module
B Heating element assembly
C Heating module PCB
D Hot water outlet
E Cold water inlet
F Temperature adjustment knob
G Flow transducer
H Terminal block (CANADA ONLY)
I 6 way terminal block
J Temperature sensor
K Control PCB
L Double pole thermal cut-out
M Inlet water filter
N Flow regulator
6720646951-14.1V
G
E
L
J
H
I
N
M
F K
A
D
C
B
