Available Accessories
The EX-1280, EX-440C, EX-1280C, and EX-12AEC processors are compatible with the Bose controllers and
endpoints listed below as well as Bose ControlSpace Remote and controllers by other manufacturers such as
Crestron® and AMX®.
Model Part Number Notes
ControlSpace EX-4ML mic/GPIO
Dante endpoint
PC 771783 Uses Dante port. Requires EX Endpoint Power
Supply (PC 800446) or Power-over-Ethernet
(PoE) switch.
ControlSpace EX-8ML mic/GPIO
Dante endpoint
PC 772045 Uses Dante port. Requires EX Endpoint Power
Supply (PC 800446) or Power-over-Ethernet
(PoE) switch.
ControlSpace EX-UH USB/Headset
Dante endpoint
PC 771784 Uses Dante port. Requires EX Endpoint Power
Supply (PC 800446) or Power-over-Ethernet
(PoE) switch.
ControlSpace CC-64 control center PC 041760 Provides network control of any Bose
networkable hardware.
ControlSpace CC-16 zone controller PC 041761 Uses CC-16 port. Up to 15 devices can be used
with the EX-1280 and EX-1280C.
ControlSpace CC-4 room controller PC 042023 Uses GPI port. Requires five control inputs
and one ground termination.
Volume Control with A/B switch
user interface
PC 041967 Uses GPI port. Requires two control inputs
and one ground termination.
Volume Control user interface PC 041966 Uses GPI port. Requires one control input and
one ground termination.
ControlSpace ControlCenter CC-1D PC 079059 (US, white)
PC 079051 (US, black)
PC 079042 (EU, white)
PC 079070 (EU, black)
PC 079062 (JP, white)
PC 079060 (JP, black)
Uses Network port. Requires additional
Power-over-Ethernet (PoE) switch.
ControlSpace ControlCenter CC-2D PC 079063 (US, white)
PC 079043 (US, black)
PC 079071 (EU, white)
PC 079049 (EU, black)
PC 079066 (JP, white)
PC 079046 (JP, black)
Uses Network port. Requires additional
Power-over-Ethernet (PoE) switch.
ControlSpace ControlCenter CC-3D PC 079061 (US, white)
PC 079047 (US, black)
PC 079053 (EU, white)
PC 079058 (EU, black)
PC 079041 (JP, white)
PC 079064 (JP, black)
Uses Network port. Requires additional
Power-over-Ethernet (PoE) switch.

Bose ControlSpace EX-1280 Specifications

General

Frequency range	18 - 20000 Hz
Channels quantity	20 channels
Product color	Black
Rack capacity	1U
Rack mounting	Yes
LED indicators	Power
Audio input	3.81 mm detachable Euroblock, 6-pin
RS-232 ports	1
USB connector type	Micro-USB B, USB Type-A
Standard interfaces	USB
Ethernet LAN (RJ-45) ports	3
Microphone included	No
DC input voltage	230 V
Power consumption (typical)	35 W
Operating temperature (T-T)	0 - 40 °C

Weight and Dimensions

Depth	282 mm
Width	483 mm
Height	44 mm
Weight	3200 g
