Technical Information
30 • English EX-440C/1280/1280C/12AEC • Installation & Operation Guide
PRO.BOSE.COM
EX-440C
Integrated DSP
Signal Processor/CPU 32-bit fixed/floating-point DSP 456 MHz/Arm Cortex-A8 600 MHz
Maximum Calculation 3.6 GIPS / 2.7 GFLOPS
Delay 43 s
Audio Latency 1.05 ms (analog in to analog out, without AEC)
A/D & D/A Converters 24-bit
Sample Rate 48 kHz
Acoustic Echo Cancellation
Tail Length 480 ms
Noise Reduction 32 dB
Latency 50 ms
Channels 8
References 4
Analog Audio Inputs
Input Channels 4 balanced, mic/line level
Input Connectors 3.81 mm, 6-pin Euroblock
Input Impedance 12 kΩ at 1 kHz (with or without phantom power active)
Maximum Input Level +24 dBu
Equivalent Input Noise −118 dB at 44 dB gain setting
Phantom Power +48 VDC, 10 mA, selectable per input
Gain Settings 0/+14/+24/+32/+44/+54/+64 dB
Analog Audio Outputs
Output Channels 4 balanced, line-level
Output Connectors 3.81 mm, 6-pin Euroblock
Output Impedance 200 Ω
Maximum Output Level +24 dBu
Audio Performance
Frequency Response 20 Hz to 20 kHz (+0.5 dB/−0.5 dB)
THD+N 0.01% at +4 dBu (A-weighted, 20 Hz to 20 kHz)
Channel Separation (Crosstalk) < −105 dB at +4 dBu input & output level, 1 kHz
Dynamic Range > 115 dB, A-weighted, 20 Hz to 20 kHz, analog input to analog output

Bose ControlSpace EX-1280 Specifications

General

Frequency range	18 - 20000 Hz
Channels quantity	20 channels
Product color	Black
Rack capacity	1U
Rack mounting	Yes
LED indicators	Power
Audio input	3.81 mm detachable Euroblock, 6-pin
RS-232 ports	1
USB connector type	Micro-USB B, USB Type-A
Standard interfaces	USB
Ethernet LAN (RJ-45) ports	3
Microphone included	No
DC input voltage	230 V
Power consumption (typical)	35 W
Operating temperature (T-T)	0 - 40 °C

Weight and Dimensions

Depth	282 mm
Width	483 mm
Height	44 mm
Weight	3200 g
