Bose FREESPACE BMA-125 User Manual

18
120V Main Assembly Part List
(Figure 1)
Reference
Designator
Description Part Number Qty See
Note
Q101, 103 Transistor (MJ 15022) 185231 2
Q102, 104 Transistor (MJ 15023) 185232 2
S101-S104 Socket, transistor, W/TO-3CA 185310 4
S101-S104 Insulator, Wafer 183311 4
T101
Power Transformer (T101) 185229 1 3
T102
Output Transformer (T102) 185230 1 3
R101-104 Pot 5K LIN PNL 185247 4
R100, 105 Pot 5K LIN PNL ADJ 185285 2
C101 Cap 220µF 100V 20% 185241 1
Cap 3300 Pf 1400V CER 185242 1 3
F101
Fuse 4A 250V SLO BLO 185245 1 3
S101
Power Switch 185271 1 3
Power Cord 185233 1
Bracket Heatsink Mtg 185234 4
Bracket Transformer 185235 1
Driver PCB 185236 1 1, 2
Tone/Volume PCB 185237 1 1, 2
Equalizer PCB 185239 1 1, 2
Heatsink 185240 1
Knob, Small 185243 7
Knob, Large 185244 1
Fuseholder 185246 3
Top Cover 185272 1
Terminal Strip, Barrier, 7Ckt 185273 1
Transistor Socket 185274 4
Connector, housing, 6 Ckt 185275 1
Foot 185276 4
2B50 Dual input module-Mic
(screws)/Stereo summing input
(AUX)
180139-2B50 2
2B37 Dual input module-Mic
(screws)/AUX
180140-2B37 2
!
!
!
!
!
!
!
