37
Input Module 2B50 Part List
Integrated Circuits
Diodes
Reference
Designator
Description Part Number See Note
R1, 2, 11, 15 5.6KΩ, 1/4W, 5% 185492
R3, 6, 7 604Ω, 1/4W, 1% 185559
R4, 5 100Ω, 1/4W, 5% 185429
R8 68Ω, 1/4W, 5% 185571
R9, 14 51KΩ, 1/4W, 5% 185425
R10 5100, 1/4W, 5% 185426
Reference
Designator
Description Part Number See Note
C1 1200 PF, CER,
50V
185574
C2-5, 8-10 .01 UF, CER, 25V 185455
C6, 7 10 UF, ELCT,
RDL, 25V
185575
C11, 12 47 UF, ELCT,
RDL, 25V
185573
C13, 20 .1 UF, CER, 50 V 185448
C14, 15 220 PF, CER, 50V 185463
C16 22 PF 185572
Reference
Designator
Description Part Number See Note
U1 SSM2017 185305
U2 LM833 185474
Reference
Designator
Description Part Number See Note
D1-6 SIGNAL 185546
Resistors
Capacitors
To Next Page
