Reference
Designator
Description Part Number See Note
R1, 2, 5, 6, 8 5.6KΩ, 5%, 1/4W,
CF
185492
R3, 4, 14, 16, 18 4.7KΩ, 5%, 1/4W,
CF
185493
R7 POT, 5KΩ, PCB
MTG
185494
R9 7.5KΩ, 5%, 1/4W,
CF
185495
R10,11 1KΩ, 5%, 1/4W,
CF
185442
R12, 13, 20 105KΩ, 1%, 1/4W 185497
R15 10KΩ, 5%, 1/4W,
CF
185433
R17 200KΩ, 5%, 1/4W,
CF
185499
R19 39Ω, 5%, 1/4W,
CF
185500
R21, 44, 55 100KΩ, 5%, 1/4W,
CF
185427
R22, 27 POT, 100KΩ, PCB
MTG
185502
R23, 25 150KΩ, 5%, 1/4W,
CF
185503
R24 20KΩ, 5%, 1/4W,
CF
185504
R26 75KΩ, 5%, 1/4W,
CF
185505
R28 91KΩ, 5%, 1/4W,
CF
185506
R29-34, R56-58 300Ω, 5%, 1/4W,
CF
185507
R35-37, 40 10KΩ, 1%, 1/4W,
MF
185508
R38, 41, 48, 53 4750Ω, 1/4W, 1% 185509
R39 22.1KΩ, 1%,
1/4W, MF
185510
R42 38.3KΩ, 1%,
1/4W, CF
185511
R43 2.4KΩ, 5%, 1/4W,
CF
185512
R45 93.1KΩ, 1/4W, MF 185513
R46 732KΩ, 1%, 1/4W,
MF
185514
R47 25.5KΩ, 1%,
1/4W, MF
185515
230V Tone/Volume/Equalizer PCB
Resistors
