Bose FREESPACE BMA-125 User Manual

23
120V Tone/Volume Control PCB
Resistors
Capacitors
Reference
Designator
Description Part Number See Note
R2, 3, 4, 5, 7, 26,
27, 28, 30
1.2KΩ, 5%, 1/4W,
CF
185393
R6 47KΩ, 5%, 1/4W,
CF
185316
R8, 39 100Ω, 5%, 1/4W
CF
185429
R9, 10, 13, 16 1.0KΩ, 5%, 1/4W,
CF
185442
R11, 40 1OKΩ, 5%, 1/4W,
CF
185433
R12 51Ω, 5%, 1/4W,
CF
185398
R14, 15, 41, 42,
43
VARISTOR-TVS
14V
185399
R17, 18 100KΩ, 5%, 1/4W,
CF
185427
R19 3.3KΩ, 5%, 1/4W,
CF
185401
R20, 21, 34 20KΩ, 5%, 1/4W,
CF
185402
R22 POT, 5KΩ, PCB,
MTG
185403
R23 8.2KΩ, 5%, 1/4W,
CF
185404
R24, 37 5.1KΩ, 5%, 1/4W,
CF
185326
R29, 31 POT, 100KΩ,
PCB, MTG
185406
R32, 33 150KΩ, 5%, 1/4W 185407
R35 75KΩ, 5%, 1/4W 185408
R36 91KΩ, 5%, 1/4W 185409
R38 75Ω, 5%, 1/4W,
CF
185410
Reference
Designator
Description Part Number See Note
C1 30 PF, 1KV, CER,
10%
185345
C2, 3, 11, 12 47 µF, 25V,
ELECT RDL
185417
C4, 5 100 µF, 25V,
ELCT RDL
185419
