Bose FREESPACE BMA-125 User Manual

27
230V Main Assembly Part List
(Figure 10, 11)
Reference
Designator
Description Part
Number
Qty See
Note
Q101, 102 Transistor, MJ 15022 185231 2
Q103, 104 Transistor, MJ 15023 185232 2
T102 Transformer, Output 185279 1
T101 Transformer, Power 185280 1 3
R107, 108 510Ω, 5%, 1/4W CF 185281 2
R109 1Ω, 5%, 1/2W CF 185282 1
R101-104 Pot, 5KΩ, Lin, Pnl Mt 185247 4
R105 Pot, 10KΩ, Lin, Pnl Mt 185284 1
R106 Pot, 5KΩ, Lin, Pnl Mt 185285 1
C113, 114 470 pF, 250V, Cer 185270 2
C119 470 pF, 500V, Cer 10% 185287 1
C104, 105,
117, 118
.001 µF, 50V, Cer 20% 185288 4
C107, 108,
110, 111
.01 µF, 50V, Cer X7R 185289 4
C101-103.
106, 109, 112,
115
.1 µF, 50V, Cer 185290 9
SW101
Power Switch 185293 1 3
SW102 Slide, SPDT 185294 1
TS101
Rcpt Spkr 185296 1
TS102 Terminal, Barrier 185297 1
TS103 Terminal Strip, 6 Cont 185298 1
TS104 Phono Jack, 3 Pos 185299 1
TS105 Phono Jack, 2 Pos 185300 1
TS106 Terminal Strip, 3 Cont 185301 1
TS107 Terminal Strip 185302 1
TS108 Terminal Strip, 3 Lug 185303 1
TS109 Terminal Strip 185304 1
(TS101- Red) Plug, Spkr Term, Red 185306 1
(TS101-Blk) Plug, Spkr Term, Blk 185307 1
P110
Rcpt, IEC W/Fuse 185308 1 3
F101
Fuse, 250V, 1.6A 185309 1 3
S101-S104 Socket, Transistor,
W/TO-3 CA
185310 4
S101-S104 Insulator Wafer 185311 4
Top Cover 185312 1
Foot 185276 4
Knob, SM, (R101-104) 185243 7
Knob, LG, (R105) 185315 1
Heat Sink 185316 2
125W Driver PCB 185278 1 1, 2
Pre AMP PCB 185277 1 1, 2
!
!
!
!
