Reference
Designator
Description Part Number See Note
R1 5.1Ω, 5%, 1/4W,
CF
185286
R2, 41 10KΩ, 5%, 1/4W,
CF
185433
R4 47KΩ, 5%, 1/4W,
CF
185316
R5 POT, 100KΩ, LIN
FLAT PCB
185317
R6 51KΩ, 5%, 1/4W,
CF
185318
R7 750Ω, 5%, 1/4W,
CF
185319
R8 680Ω, 5%, 1/4W,
CF
185320
R9 470Ω, 5%, 5W 185321
R10, 11 10Ω, 5%, 1/4W,
CF
185322
R12 2.4KΩ, 5%, 1/4W,
CF
185323
R13 6.8KΩ, 5%, 1/4W,
CF
185324
R14 180KΩ, 5%,1/4W,
CF
185325
R15, 40 5.1KΩ, 5%, 1/4W,
CF
185326
R16 1.5Ω, 5%, 1/4W,
CF
185327
R17 150Ω, 5%, 1/4W,
CF
185328
R18, 21, 22, 26,
27, 30
100Ω, 5%, 1/4W,
CF
185329
R19 3.9Ω, 5%, 5W 185330
R20 POT, 200Ω, LIN
FLAT PCB
185331
R23 620Ω, 5%, 5W 185332
R24, 29, 36 1.0KΩ, 5%, 1/4W,
CF
185442
R25, 28, 46, 47 120Ω, 5%, 1/4W,
CF
185334
R31-34 .22Ω, 5%, 5W 185335
R35 360Ω, 5%, 2W 185336
R37 43KΩ, 5%, 1/4W,
CF
185337
120V AMP PCB
Resistors
