Bose FREESPACE BMA-125 User Manual

36
Reference
Designator
Description Part Number See Note
R1, 10 56KΩ, 1/4W, 5% 185394
R2, 11 24KΩ, 1/4W, 5% 185405
R3, 12 820Ω, 1/4W, 5% 185422
R4, 15 10KΩ, 1/4W, 5% 185433
R5, 7, 13, 14 20KΩ, 1/4W, 5% 185402
R8 1.8KΩ, 1/4W, 5% 185386
R9, 16 1KΩ, 1/4W, 5% 185442
R17 22KΩ, 1/4W, 5% 185329
Reference
Designator
Description Part Number See Note
C1, 2, 10, 11 .01µF, 50V, CER 185416
C3, 12 100pF, 50V, CER 185453
C4 33µF, 25V, Elect 185418
C13-16 47µF, 25V, Elect 185417
C17, 18 .68µF, 50V, Elect 185338s
Reference
Designator
Description Part Number See Note
U1, 2 LM833 108474
Reference
Designator
Description Part Number See Note
J1 Friction lock, 5
Crkt
185333
T1, 2
Transformer 185313
Input Module 2B37 Part List
Capacitors
Resistors
Integrated Circuits
Miscellaneous
