Bose L1 1S User Manual

25
Electrical Part List
Resistors
Input/Output and DSP PCB Assembly
Reference
Designator
Description
V
endor Part
Number
Note
R98 FERRITE-CORE, 0603, 2.5K, 50MA, 100MHZ,
HZ0603A252R
1808-0906 4
R99 FERRITE-CORE, 0603, 2.5K, 50MA, 100MHZ,
HZ0603A252R
1808-0906 4
R100 100K, RMG, 1/16W, 1%, 0603 4723-104A 4
R101 100K, RMG, 1/16W, 1%, 0603 4723-104A 4
R102 10K, RMG, 1/16W, 1%, 0603/1608 4723-103A 4
R103 10K, RMG, 1/16W, 1%, 0603/1608 4723-103A 4
R104 10K, RMG, 1/16W, 1%, 0603/1608 4723-103A 4
R105 10K, RMG, 1/16W, 1%, 0603/1608 4723-103A 4
R106 10K, RMG, 1/16W, 1%, 0603/1608 4723-103A 4
R107 10K, RMG, 1/16W, 1%, 0603/1608 4723-103A 4
R108 10K, RMG, 1/16W, 1%, 0603/1608 4723-103A 4
R109 10K, RMG, 1/16W, 1%, 0603/1608 4723-103A 4
R110 10K, RMG, 1/16W, 1%, 0603/1608 4723-103A 4
R111 10K, RMG, 1/16W, 1%, 0603/1608 4723-103A 4
R112 10K, RMG, 1/16W, 1%, 0603/1608 4723-103A 4
R113 10K, RMG, 1/16W, 1%, 0603/1608 4723-103A 4
R114 5.6K, RMG, 1/16W, 1%, 0603/1608 4723-562A 4
R115 4.99K, RMG, 1/16W, 1%, 0603 4723-562A 4
R116 2.7K, RMG, 1/16W, 1%, 0603/1608 4723-272A 4
R117 4.7K, RMG, 1/16W, 1%, 0603/1608 4723-472A 4
R118 10K, RMG, 1/16W, 1%, 0603/1608 4723-103A 4
R119 2.7K, RMG, 1/16W, 1%, 0603/1608 4723-272A 4
R120 15K, RMG, 1/16W, 1%, 0603/1608 4723-153A 4
R121 15K, RMG, 1/16W, 1%, 0603/1608 4723-153A 4
R123 10K, RMG, 1/16W, 1%, 0603/1608 4723-103A 4
R127 10K, RMG, 1/16W, 1%, 0603/1608 4723-103A 4
R130 4.7K, RMG, 1/16W, 1%, 0603/1608 4723-472A 4
R131 4.7K, RMG, 1/16W, 1%, 0603/1608 4723-472A 4
R132 47K, RMG, 1/16W, 5%, 0603/1608 4723-473J 4
R133 47K, RMG, 1/16W, 5%, 0603/1608 4723-473J 4
R135 100K, RMG, 1/16W, 1%, 0603 4723-104A 4
R136 10K, RMG, 1/16W, 1%, 0603/1608 4723-103A 4
R137 10K, RMG, 1/16W, 1%, 0603/1608 4723-103A 4
R138 10K, RMG, 1/16W, 1%, 0603/1608 4723-103A 4
R139 100R, RMG, 1/16W, 1%, 0603 4723-101A 4
R140 100R, RMG, 1/16W, 1%, 0603 4723-101A 4
R141 4.7K, RMG, 1/16W, 1%, 0603/1608 4723-472J 4
R142 470R, RMG, 1/16W, 5%, 0603/1608 4723-471J 4
R143 10KX4, RCFA, 1/16W, 5%, 0603 4703-103J04 4
R144 10KX4, RCFA, 1/16W, 5%, 0603 4703-103J04 4
R145 10K, RMG, 1/16W, 1%, 0603/1608 4723-103A 4
R146 10K, RMG, 1/16W, 5%, 0603/1608 4723-103J 4
R147 18K, RMG, 1/16W, 1%, 0603/1608 4723-183A 4
R148 4.99K, RMG, 1/16W, 1%, 0603 4723-562A 4
R149 10K, RMG, 1/16W, 5%, 0603/1608 4723-103J 4
