Bose L1 1S User Manual

39
Electrical Part List
Resistors
SMPS / Power Amplifier PCB Assembly
Reference
Designator
Description
V
endor Part
Number
Note
R1 1K, RMG, 1/16W, 1%, 0603/1608 4723-102A 4
R3 1K, RMG, 1/16W, 1%, 0603/1608 4723-102A 4
R4 10K, RMG, 1/16W, 1%, 0603/1608 4723-103A 4
R5 1K, RMG, 1/16W, 1%, 0603/1608 4723-102A 4
R6 4.7K, RMG, 1/16W, 1%, 0603/1608 4723-472A 4
R7 16K, RMG, 1/10W, 1%, 0805 4720-163A 4
R8 12K, RMG, 1/4W, 1%, 1206 4725-123A 4
R9 9.1K, RMG, 1/10W, 1%, 0805 4720-912A 4
R10 9.1K, RMG, 1/10W, 1%, 0805 4720-912A 4
R11 2.2R, RMG, 1/16W, 5%, 0603/1608 4723-2R2J 4
R12 2.2R, RMG, 1/16W, 5%, 0603/1608 4723-2R2J 4
R13 1M, RMG, 1/16W, 5%, 0603/1608 4723-105J 4
R14 1M, RMG, 1/16W, 5%, 0603/1608 4723-105J 4
R15 1.5K, RMG, 1/16W, 1%, 0603/1608 4723-152A 4
R16 0R, RMG, 1/10W, 5%, 0805 4720-000J 4
R17 8.2K, RMG, 1/16W, 5%, 0603/1608 4723-822J 4
R18 6.8K, RMG, 1/16W, 1%, 0603/1608 4723-682A 4
R19 9.1K, RMG, 1/10W, 1%, 0805 4720-912A 4
R20 4R7, RWR, 5W, 5%, RL 474B-4R7J 4
R21 64.9K, RMG, 1/16W, 1%, 0603 4723-6492 4
R22 0R, RMG, 1/10W, 5%, 0805 4720-000J 4
R23 9.1K, RMG, 1/10W, 1%, 0805 4720-912A 4
R24 3.3K, RMG, 1/16W, 1%, 0603/1608 4723-332A 4
R25 3.3K, RMG, 1/16W, 1%, 0603/1608 4723-332A 4
R26 64.9K, RMG, 1/16W, 1%, 0603 4723-6492 4
R27 4.7K, RMG, 1/16W, 1%, 0603/1608 4723-472A 4
R28 1K, RMG, 1/16W, 1%, 0603/1608 4723-102A 4
R29 12K, RMG, 1/4W, 1%, 1206 4725-123A 4
R30 16K, RMG, 1/10W, 1%, 0805 4720-163A 4
R31 1.5K, RMG, 1/16W, 1%, 0603/1608 4723-152A 4
R32 8.2K, RMG, 1/16W, 5%, 0603/1608 4723-822J 4
R34 51R, RMG, 1/4W, 1%, 1206 4725-510A 4
R35 51R, RMG, 1/4W, 1%, 1206 4725-510A 4
R36 0R, RMG, 1/16W, 5%, 0603 4723-000J 4
R40 100R, RMG, 1/10W, 5%, 0805 4720-101J 4
R41 4R7, RWR, 5W, 5%, RL 474B-4R7J 4
R44 10K, RMG, 1/16W, 1%, 0603/1608 4723-103A 4
R45 100R, RMG, 1/16W, 1%, 0603 4723-101A 4
R46 100R, RMG, 1/16W, 1%, 0603 4723-101A 4
R47 100R, RMG, 1/16W, 1%, 0603 4723-101A 4
R48 100R, RMG, 1/16W, 1%, 0603 4723-101A 4
R49 47K, RMG, 1/16W, 1%, 0603/1608 4723-473A 4
R50 47K, RMG, 1/16W, 1%, 0603/1608 4723-473A 4
R51 47K, RMG, 1/16W, 1%, 0603/1608 4723-473A 4
R52 1.8K, RMG, 1/16W, 1%, 0603/1608 4723-182A 4
R53 1K, RMG, 1/16W, 1%, 0603/1608 4723-102A 4
R54 1K, RMG, 1/16W, 1%, 0603/1608 4723-102A 4
