Bose L1 1S User Manual

47
Electrical Part List
Miscellaneous (continued)
Miscellaneous
AC Primary PCB Assembly
Reference
Designator
Description
V
endor Part
Number
Note
E1A SPADE TERMINAL, 6.3X0.8, STRAIGHT 2101-1231+0
E2A SPADE TERMINAL, 6.3X0.8, STRAIGHT 2101-1231+0
E3A SPADE TERMINAL, 6.3X0.8, STRAIGHT 2101-1231+0
P1 SPADE TERMINAL, 6.3X0.8, STRAIGHT 2101-1231+0
P2 SPADE TERMINAL, 6.3X0.8, STRAIGHT 2101-1231+0
CON300B WAFER, 3P, P7.92/11.88, STRAIGHT 2101-3097+0
CON300L WAFER, 3P, P7,.92/11.88, STRAIGHT 2101-3097+0
J105 INLET, AC, UL/CSA/VDE, 250V, 10A 2113-1144+0 3
J105-1 BRACKET, A/C INLET, SECC,
BSPAPS2+05CS11
4135-6791+1
SMPS / Power Amplifier PCB Assembly
Reference
Designator
Description
V
endor Part
Number
Note
N101 THERMISTER, NTC 5 0HM, 4A, NIOSP005L,
UL/CSA/VDE
5202-0010 4
N200 THERMISTOR, PTC, 1K, 0805, 90 DEG, EPCOS 5202-0011 4
N201 THERMISTOR, PTC, 1K, 130 DEG, 0805,
EPCOS
5202-0021 3,4
S100 WIRE JUMPER, ROLLER FORM, D=0.6MM 635N-0002 4, 120V
ONLY
S301 WIRE JUMPER, ROLLER FORM, D=0.6MM 635N-0002 4
S302 WIRE JUMPER, ROLLER FORM, D=0.6MM 635N-0002 4
TRAF200 TRANSFORMER, SW, ETD29, WAH HING
1806-3898?
3,4
