Bose L1 1S User Manual

35
Electrical Part List
Inductors
Diodes
Input/Output and DSP PCB Assembly
Reference
Designator
Description
V
endor Part
Number
Note
L100 FERRITE, CHIP, 0603, BLM18AG102SN1D,
MURATA
1808-0878 4
L101 FERRITE BEAD, SMD, ACB453215, 125 OHM 1802-0630 4
L102 FERRITE BEAD, SMD, ACB453215, 125 OHM 1802-0630 4
L104 FERRITE BEAD, SMD, ACB453215, 125 OHM 1802-0630 4
L105 FERRITE BEAD, SMD, ACB453215, 125 OHM 1802-0630 4
L106 FERRITE BEAD, SMD, ACB453215, 125 OHM 1802-0630 4
L107 FERRITE BEAD, SMD, ACB453215, 125 OHM 1802-0630 4
L108 FERRITE BEAD, SMD, ACB453215, 125 OHM 1802-0630 4
L109 FERRITE BEAD, SMD, ACB453215, 125 OHM 1803-0103 4
L110 FERRITE BEAD, SMD, ACB453215, 125 OHM 1802-0630 4
L111 FERRITE BEAD, SMD, ACB453215, 125 OHM 1802-0630 4
L112 INDUCTOR, 22uH, 20%, 8.1X8, B1000AS-
220M=P3, SMD, TOKO
1803-0103 4
L113 FERRITE BEAD, SMD, ACB453215, 125 OHM 1802-0630 4
L116 FERRITE BEAD, 4.5X1.6X1.6,
BLM41PG102SN1L, MURATA
1808-0871 4
L117 FERRITE BEAD, 4.5X1.6X1.6,
BLM41PG102SN1L, MURATA
1808-0871 4
L302 FERRITE BEAD, SMD, ACB453215, 125 OHM 1802-0630 4
L303 FERRITE BEAD, SMD, ACB453215, 125 OHM 1802-0630 4
Reference
Designator
Description
V
endor Part
Number
Note
D100 SCHOTTKY, 40V, 3A, ST, PS3L40S, DO-214AB,
SMD, ST
480L-40S0 4
D101 BAV99, SOT23, PHILIPS 4840-8970 4
D102 BAV99, SOT23, PHILIPS 4840-8970 4
D103 BAV99, SOT23, PHILIPS 4840-8970 4
D104 SCHOTTKY, 40V, 3A, ST, PS3L40S, DO-214AB,
SMD, ST
480L-40S0 4
D105 1SS355TE-17, ROHM 4840-1660 4
D106 1SS355T
E
-17, ROHM 4840-1660 4
D107 1SS355T
E
-17, ROHM 4840-1660 4
D108 1SS355TE-17, ROHM 4840-1660 4
D109 BAV99, SOT23, PHILIPS 4840-8970 4
D110 BAV99, SOT23, PHILIPS 4840-8970 4
D111 SCHOTTKY, SK16, DO-214AA, 60V, 1A, SMD,
PANJIT
480S-K160 4
D112 SCHOTTKY, SK16, DO-214AA, 60V, 1A, SMD,
PANJIT
480S-K160 4
D118 LOW CURRENT SMD, LED, RED 2mA 3700-7829 4
D119 LED, SMD, 3.2X2.4X2.4, RD 3700-7840 4
D120 LED, SMD, 3.2X2.4X2.4, RD 3700-7840 4
D121 LED, SMD, 3.2X2.4X2.4, RD 3700-7840 4
D122 LED, SMD, 3.2X2.4X2.4, RD 3700-7840 4
