Bose L1 1S User Manual

4
Specifications
External Dimensions
Cylindrical Line Array: Height: 2070 mm ± 30 mm. Width: 89 mm ± 5 mm.
Depth: 120 mm ± 5 mm
Line Array Extension: Height: 978 mm ± 30 mm. Width: 89 mm ± 5 mm.
Depth: 120 mm ± 5 mm
Power Stand: Height: 110 mm ± 20mm. Width: 200 mm ± 10mm
Depth: 660 mm ± 10mm (Legs Folded Closed)
Bass Module: Height: 628 mm ± 10 mm Width: 342 mm ± 10
Depth: 460 mm ± 10 mm
Weight
Cylindrical Line Array: 16 lbs ±2 lbs. (7.3 kg ± 0.9 kg).
Line Array Extension: 8.0 lbs ±2 lbs. (3.6 kg ± 0.9 kg).
Power Stand: 20 lbs ± 2 lbs. (9.1 kg ± 0.9 kg)
Bass Module: 45 lbs
Note: PS15 + L15 Line Array + L15 Extension - 44 lbs
Input / Output Panel Connections
Line-level Inputs: (1) Input (1/4in” TRS)
Speaker Outputs: (1) Bass Out (Neutrik NL4)
Data In & Power: (1) Ethercon / RJ45
Power Input: (1) IEC Connector - recessed
Input/Output Panel Controls
Input Trim (1) Input trim knob - adjusts analog input level
Display (1) LED for Preamp signal present and clipping on the
Power Stand.
(1) LED of Power On and Fault Condition Display
Note: All measurements are made in “Debug” mode [ No EQ or Limiting]
Electrical Specifications
Description System State Specification
Output Power 4 Ohm Load, L15 Speaker out and
Bass s
p
eaker out
p
u
t
Line Array – 125W
Bass Module - 250W
S/N Ratio, A-wtd. re Max
Output, Nominal Settings,
Line Input
Trim @ 12:00, Adj. Vin for 250W, L2
and bass spkr outputs
90dB Min
S/N Ratio,
A
-wtd. re Max
Output, Nominal Settings,
S/PDIF Input 1 or 2
Adj. S/PDIF for 250W (-18 dBFS
input) , L2 and bass spkr outputs
90dB Min
Frequency Response, any
input to any output
Trim @ 12:00, -20 dBV Line input, or -
38 dBFS S/PDIF input
20Hz to 20kHz +/- 1dB
Balanced ¼” Line Input
Description System State Specification
Input Impedance (Unbal) 10 kOhm +/- 10%
Maximum Input Voltage Trim @ Min, 20 Vpp input <1% THD, all outputs
