Bose SoundTouch Service Manual

2
CONTENTS
CAUTION: The Bose
®
SoundTouch
TM
Wireless Pedestal contains no user-serviceable
parts. To prevent warranty infractions, refer servicing to warranty service stations or
factory service.
PROPRIETARY INFORMATION
THIS DOCUMENT CONTAINS PROPRIETARY INFORMATION OF
BOSE CORPORATION WHICH IS BEING FURNISHED ONLY FOR
THE PURPOSE OF SERVICING THE IDENTIFIED BOSE PRODUCT
BY AN AUTHORIZED BOSE SERVICE CENTER OR OWNER OF
THE BOSE PRODUCT, AND SHALL NOT BE REPRODUCED OR
USED FOR ANY OTHER PURPOSE.
The Bose SoundTouch Wireless Pedestal is covered by a 1-year limited warranty.
WARRANTY
PART LIST NOTES
1. The individual parts located on the PCBs are listed in the Electrical Part List.
2. This part is referenced for informational purposes only. It is not stocked as a repair part.
Refer to the next higher assembly for a replacement part.
3. This part is critical for safety purposes. Failure to use a substitute replacement with
the same safety characteristics as the recommended replacement part might create shock,
fire and/or other hazards.
4. When replacing the programmed Wi-Fi module, the serial number and country code must be
set on the replacement board before returning the unit to the customer. Refer to pages 35
and 36 for procedures.
Product Description ..................................................................................................................... 3-4
Packaging Part List, SoundTouch
TM
Wireless Pedestal (refer to Figure 1)................................5
Figure 1. Packaging View .................................................................................................................5
Main Part List, SoundTouchTM Wireless Pedestal (refer to Figure 2).......................................6
Figure 2. Exploded View ...................................................................................................................7
Electrical Part Lists .................................................................................................................... 8-30
Wi-Fi Module PCB Assembly...................................................................................................... 8-26
Input / Output PCB Assembly .................................................................................................. 26-30
Disassembly Procedures ...............................................................................................................31
TAP Command Setup......................................................................................................................32
Wi-Fi Test Procedures....................................................................................................................33
Test Procedures .............................................................................................................................34
Serial Number and Country Code Programming.........................................................................35
TAP Commands ......................................................................................................................... 36-37
Service Manual Revision History .................................................................................................38

Bose SoundTouch Specifications

General

Number of drivers	-
Number of speakers	1
Audio output channels	2.0 channels
Recommended usage	Universal
Remotely operated	Yes
Card reader integrated	No
Product type	Stereo portable speaker
Product color	Black
Product design	Other
Volume control	Digital
Impedance	- Ω
Frequency range	- Hz
RMS rated power	- W
Display	OLED
Depth (imperial)	2.5 \
Width (imperial)	9.8 \
Height (imperial)	5.8 \
Cables included	AC
Quantity per pack	1 pc(s)
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Connectivity technology	Wireless
Power source type	Battery

Weight and Dimensions

Depth	64 mm
Width	249 mm
Height	147 mm
Weight	1448 g
