Bose SoundTouch Service Manual

36
1. Connect to Router
1.1 No security
“airplay wifi profile [network_name]” connects
to a network w/ no security
1.2 WPA security
“airplay wpa profile [network_name] [security]
[passphrase]” for WPA where security is
TKIP or AES
1.3 WEP security
“airplay wep profile [network_name] [key]” for
WEP security
2. Play Song from Demo URL
2.1 View Current system configuration
“getpdo CurrentSystemConfiguration” will
print out the current values
2.2 Enter location of demo URL
“sys configuration DemoAudioURL http://
worldwide.bose.com/downloads/assets/
audio/take5.mp3”
2.3 Enable Demo
“sys configuration DemoNetworkEnabled
true”
2.4 Enter Demo mode
“demo enter”
2.5 Exit Demo Mode
“demo exit” or “sys reboot”
3. Enter Manufacturing mode
3.1 As soon as the unit starts to boot, hold
shift and press “U” repeatedly until “U-Boot#”
prompt is displayed. This will interupt the
normal boot process.
3.2 At the U-Boot# prompt, enter TAP com-
mand “setenv variant_mode mfg”
3.3 Enter TAP command “boot” to reboot unit
into manufacturing mode.
4. Set Country Code
The Wi-FI module can be set to EU or US
standard, which determines which Wi-Fi
channels are used. All countries outside the
US are set to the EU Code. EU 1-13 ch , US
1-11 ch
4.1 Enter Manufacturing Mode (Procedure 3)
4.2 At the “->” prompt, enter TAP command
“d dm870 cc (EU or US).
4.3 Enter TAP command “d reset” to reboot
into normal mode.
5. Check Country Code.
5.1 Type the command “local_services on”
and <enter>. Then press CTRL-C on the
keyboard. Then type “e” and <enter>. The
command line spotty login: should be dis-
played
on the computer.
5.2 Enter TAP command “root” and <enter>.
The command line should be
root@spotty:root#.
5.3 Enter “cat /var/tmp/mfgdata.xml” without
the quotes. The country code is displayed in
the first line of the response.
5.4 Return to CLI prompt by entering the
command “rm /mnt/nv/local_services” and
<enter>.
5.5 Enter the command “exit” and <enter>.
This will return to the TAP interface (CLI) and
a TAP command line “->” should be shown.
TAP COMMANDS
