Bose SoundTouch Service Manual

8
ELECTRICAL PART LIST
Wi-Fi Module PCB Assembly
Resistors
Reference
Designator
Description Part Number Note
R13 51 OHM, 0402 ARRAY, 4 5%, 0.063W 354737-510J4
R14 51 OHM, 0402 ARRAY, 4 5%, 0.063W 354737-510J4
R15 0 OHM, JUMPER, 0402 280043
R16 0 OHM, JUMPER, 0402 280043
R27 220 OHM, 0402 ARRAY, 4 5%, 0.063W 354737-221J4
R123 121 Ohm, 0402, 63mw, 1% 268361-121R
R124 30.1 OHMS, 0402, 0.063W, 1% 268361-30R1
R125 5.76K, 0402, 63MW, 1% 268361-5761
R126 5.76K, 0402, 63MW, 1% 268361-5761
R127 5.76K, 0402, 63MW, 1% 268361-5761
R128 187 OHMS, 0402, 63mw, 1% 268361-187R
R129 187 OHMS, 0402, 63mw, 1% 268361-187R
R132 392 OHM, 0402, 63MW, 1% 268361-392R
R133 51 OHMS, 0402, 0.063W, 1% 268361-51R0
R134 100 OHM, 0402, 63MW, 1% 268361-1000
R135 100 OHM, 0402, 63MW, 1% 268361-1000
R136 100 OHM, 0402, 63MW, 1% 268361-1000
R137 100 OHM, 0402, 63MW, 1% 268361-1000
R138 0 OHM, JUMPER, 0402 280043
R139 0 OHM, JUMPER, 0402 280043
R140 100 OHM, 0402, 63MW, 1% 268361-1000
R141 3.01K, 0402, 63MW, 1% 268361-3011
R142 10.0K, 0402, 63MW, 1% 268361-1002
R143 10.0K, 0402, 63MW, 1% 268361-1002
R144 10.0K, 0402, 63MW, 1% 268361-1002
R146 JUMPER, CHIP, 0603 196042
R147 JUMPER, CHIP, 0603 196042
R200 10.0K, 0402, 63MW, 1% 268361-1002
R201 13.0K, 0402, 63MW, 1% 268361-1302
R202 6.04K, 0402, 63MW, 1% 268361-6041
R203 10.0K, 0402, 63MW, 1% 268361-1002
R204 10.0K, 0402, 63MW, 1% 268361-1002
R205 2.74K, 0402, 63MW, 1% 268361-2741
R206 100 OHM, 0402, 63MW, 1% 268361-1000
R207 1.50K, 0402, 63MW, 1% 268361-1501
R208 10.0K, 0402, 63MW, 1% 268361-1002
R209 10.0K, 0402, 63MW, 1% 268361-1002
R210 10.0K, 0402, 63MW, 1% 268361-1002
R211 10.0K, 0402, 63MW, 1% 268361-1002
R212 0 OHM, JUMPER, 0402 280043
R213 0 OHM, JUMPER, 0402 280043
R214 10.0K, 0402, 63MW, 1% 268361-1002
R215 100 OHM, 0402, 63MW, 1% 268361-1000
R216 100 OHM, 0402, 63MW, 1% 268361-1000
R217 10.0K, 0402, 63MW, 1% 268361-1002
R218 10.0K, 0402, 63MW, 1% 268361-1002
R219 4.75K, 0402, 0.063W, 1% 268361-4751

