Bose SoundTouch Service Manual

27
ELECTRICAL PART LIST
Input / Output PCB Assembly
Resistors (continued)
Capacitors
Reference
Designator
Description Part Number Note
R409 0.051 OHM, 0805, .25W, 5% 317342-R051
R410 0.33 OHM, 0805, 100mW, 1% 268386-R33
R411 10K, 0603, .1W, 1% 191465-1002
R412 1.00K, 0402, 63MW, 1% 268361-1001
R413 1 OHM, 0402, 0.063W, 1% 268361-1R00
W301 JUMPER, CHIP, 0603 196042
W302 JUMPER, CHIP, 0603 196042
W303 JUMPER, CHIP, 0603 196042
W304 JUMPER, CHIP, 0603 196042
W401 JUMPER, CHIP, 0603 196042
W403 JUMPER, CHIP, 0603 196042
W404 JUMPER, CHIP, 0603 196042

Reference
Designator
Description Part Number Note
C200 100pF, C0G, 0603, 50V, 5% 188454-101
C201 100
p
F, C0G, 0603, 50V, 5% 188454-101
C202 100pF, C0G, 0603, 50V, 5% 188454-101
C203 0.10uF, 0603, 16V, 5% 258498-104
C204 470pF, 0603, X7R, 50V 191470-471
C205 0.10uF, 0603, 16V, 5% 258498-104
C206 1000pF, C0G, 0603, 50V, 5% 188454-102
C207 1000pF, 0603, X7R, 50V 191470-102
C208 100
p
F, C0G, 0603, 50V, 5% 188454-101
C209 100pF, C0G, 0603, 50V, 5% 188454-101
C210 0.10uF, 0603, 16V, 5% 258498-104
C211 47pF, COG, 0402, 50V, 5% 268364-470
C212 47
p
F, COG, 0402, 50V, 5% 268364-470
C301 0.1uF, X7R, 0603, 10%, 50V 191470-104
C302 1000pF, X7R, 1206, 2000V, 20% 359294-102M
C303 0.1uF, X7R, 0603, 10%, 50V 191470-104
C304 0.1uF, X7R, 0603, 10%, 50V 191470-104
C305 10uF, X5R, 0805, 25V, 10% 273592-106E
C306 10uF, X5R, 0805, 25V, 10% 273592-106E
C307 5.1
p
F 0.25
p
F, COG, 0402, 50V 317398-5R1CH
C308 5.1pF 0.25pF, COG, 0402, 50V 317398-5R1CH
C309 5.1pF 0.25pF, COG, 0402, 50V 317398-5R1CH
C310 5.1pF 0.25pF, COG, 0402, 50V 317398-5R1CH
C311 100uF, EL, SMD, 105C, 16V, 20% 306169-101CF
C401 470pF, COG, 0402, 5%, 50V 268364-471
C402 0.1uF, X7R, 0603, 10%, 50V 191470-104
C403 68pF, COG, 0402, 50V, 5% 268364-680
C404 3.3nF, X7R, 0402, 25V, 5% 268367-332
C405 680pF, C0G, 0402, 50V, 5% 268364-681
C406 1000pF, 0603, X7R, 50V 191470-102
C407 100pF, C0G, 0603, 50V, 5% 188454-101

