Bose SoundTouch Service Manual

23
Wi-Fi Module PCB Assembly
ELECTRICAL PART LIST
Capacitors (continued)
Ferrite Beads
Inductors
Reference
Designator
Description Part Number Note
C7105 10nF, X7R, 0402, 25V, 5% 268367-103
C7106 10nF, X7R, 0402, 25V, 5% 268367-103
C7107 10nF, X7R, 0402, 25V, 5% 268367-103
C7108 10nF, X7R, 0402, 25V, 5% 268367-103
C7109 10nF, X7R, 0402, 25V, 5% 268367-103
C7110 10nF, X7R, 0402, 25V, 5% 268367-103
C7111 10nF, X7R, 0402, 25V, 5% 268367-103
C7112 10nF, X7R, 0402, 25V, 5% 268367-103
C7113 10nF, X7R, 0402, 25V, 5% 268367-103

Reference
Designator
Description Part Number Note
L18 FERRITE, BEAD, 0603, BLM18P, 120 OHMS 302257-121
L22 INDUCTOR, HI FREQ, 0402, 125C, 4.7nH 354810-4R7S
L24 INDUCTOR, HI FREQ, 0402, 125C, 1.8nH 354810-1R8S
L38 0 OHM, JUMPER, 0402 280043
L1200 INDUCTOR, 0504, 90 OHMS, 150mA, C- MODE 324381-090D
L1300 INDUCTOR, POWER, 2520, 125C, 20%, 4.7uH 348739-4R7M
L1301 INDUCTOR, POWER, 2520, 125C, 20%, 2.2uH 348739-2R2M
L1302 INDUCTOR, POWER, 2520, 125C, 20%, 2.2uH 348739-2R2M

Reference
Designator
Description Part Number Note
FB300 BEAD, FERRITE, 0805, 1.5A, 330 OHM 267539-331
FB301 FERRITE BEAD, CHIP, 0603, 120 OHM 259925-121
FB302 FERRITE BEAD, CHIP, 0603, 120 OHM 259925-121
FB303 FERRITE BEAD, CHIP, 0603, 120 OHM 259925-121
FB304 FERRITE BEAD, CHIP, 0603, 120 OHM 259925-121
FB305 FERRITE BEAD, CHIP, 0603, 120 OHM 259925-121
FB306 FERRITE BEAD, CHIP, 0603, 120 OHM 259925-121
FB307 BEAD, FERRITE, 0805, 1.5A, 330OHM 267539-331
FB900 BEAD, FERRITE, 0402, 120 OHM, 0.3A 324216-121B
FB1100 BEAD, FERRITE, 0402, 120 OHM, 0.3A 324216-121B
FB1101 BEAD, FERRITE, 0402, 120 OHM, 0.3A 324216-121B
FB1102 BEAD, FERRITE, 0402, 120 OHM, 0.3A 324216-121B
FB1103 BEAD, FERRITE, 0402, 120 OHM, 0.3A 324216-121B
FB1104 BEAD, FERRITE, 0402, 120 OHM, 0.3A 324216-121B
FB1106 BEAD, FERRITE, 0402, 120 OHM, 0.3A 324216-121B
FB1107 BEAD, FERRITE, 0402, 120 OHM, 0.3A 324216-121B
FB1202 FERRITE BEAD, CHIP, 0603, 120 OHM 259925-121
FB1203 FERRITE BEAD, CHIP, 0603, 120 OHM 259925-121
FB1300 FERRITE BEAD, 1206, 120 OHM 326348-121
FB1502 FERRITE BEAD, CHIP, 0603, 120 OHM 259925-121
FB1503 BEAD, FERRITE, 0805, 1.5A, 330 OHM 267539-331

