Page 20
Pump Module Parts List
NL917IB-2 NL917FIB-2
Item Qty. Description NL919IB-2 NL919FIB-2
1 Pump Module (complete), 12 Volt, Rear 947-4516RNA 947-4516FNA
1 1 Pump Assembly (M268-0117) 12V-120G - Triple Relief (Includes Items 1 & 2) 34330-12V 34330-12V
2 1 Solenoid, Up - 4-Post Trombetta - Angle 35310 35310
3 1 Housing, Pump
(Complete Assembly 947-2513RNA or 947-2513FNA Includes Items 3 - 20)
947-2513RN 947-2513FN
4 1 Beeper, Constant - High Output 33251 33251
5 1 Switch, Toggle w/ Gold Contacts 31787 31787
6 1 Stud, Power Feed 26084 26084
7 1 Lens, Threshold Warning - Red 30704 30704
8 1 Spacer, Lens - NHTSA 31386 31386
9 1 Metal Ring Base - Lamp 30971 30971
10 1 Socket, Lamp 30703 30703
11 3 Screw, #8-32 x 1/2" Pan Head Phillips - Thread Cut 30974 30974
12 1 Bulb, Light 19841 19841
13 2 Clamp, Spring - Pump Handle 12350 12350
14 4 Rivet, Pop, SD43BS - 1/8" - .13"/.19" 12954 12954
15 6 Rivet, Pop, SD64BS - 3/16" - .13"/.25" 11513 11513
16 1 Screw, #10-32 x 3/8", T-Head, Thumb 33435 33435
17 3 Washer, #10 Flat 11541 11541
18 1 Diode, Green LED 29545 29545
19 1 Circuit Breaker, Manual Reset - 15 Amp 35143 35143
20 1 Clamp, Hose - Solenoid Mounting 29663 29663
21 2 Fitting, Male 7/16-20 O-Ring to Male 7/16-20 JIC 37° 24504 24504
22 1 Elbow, Female Swivel 7/16-20 JIC 37° to (2) Male 7/16-20 JIC 37° 26579 26579
23 4 Rivet, Snap, .122" Dia. - .158" -.197" Thick 25759 25759
24 4 Washer, 5/16" External Tooth 16368 16368
25 2 Bolt, 5/16-18 x 3/4", Nylock, Hex * See note below 29608 29608
26 2 Bolt, 5/16-18 x 1/2", Nylock, Hex * See note below 10012 10012
27 1 Cover, Pump Module 947-2519RN 947-2519FN
28 1 Pump Handle with Grip 17206A 17206A
29 1 Cycle Counter, LCD w/o Reset 30547 30547
30 1 Flasher, 12V 32461 32461
31 2 Relay, 30/40A SPDT 12V with Internal Diode 35249 35249
32 1 Harness, Main 947-2500NA 947-2500NA
33 1 Cable, Pump Module Power 26082A-4 26082A-4
34 1 Cable, Lift / Chassis Ground 22166A 22166A
35 1 Wire Assembly, Lift Interlock Connection 31797A 31797A
36 1 Wire Assembly, Lift Stowed Connection See note below 31798A 31798A
37 1 Rubber Boot, Red See note below
82046 82046
38 1 Control, Hand Pendant Assembly - Non Electronic / Non Shielded - Coiled See note below 33659A 33659A
39 1 Diode Assembly, Up Solenoid 73906A 73906A
40 1 Harness, Lift Power See note below 33688A 33688A
41 1 Harness, Tower / Opposite Pump (Not shown - see Wiring Diagram) 33231A 33231A
42 1 Harness, Bridge Inputs (Not shown - see Wiring Diagram) 33249RA 33249RA
43 1 Harness, IB Occupied / Stow (Not shown - see Wiring Diagram) 33257A 33257A
44 1 Harness, Tower / Pump Side (Not shown - see Wiring Diagram) 33255A 33255A
45 1 Harness, Extension Lighting - 54" (Not shown - see Wiring Diagram) 31033A54 31033A54
46 1 Harness, Extension Lighting - 99" (Not shown - see Wiring Diagram) 31033A99 31033A99
47 1 Hose Assembly, 86" - 1/8" Dia. - Swivel Ends (Not shown - see Hydraulic Diagram) 16004A-086 16004A-086
48 1 Hose Assembly, 46" - 1/8" Dia. - Swivel Ends (Not shown - see Hydraulic Diagram) 16004A-046 16004A-046
49 1 Hose Assembly, 3/16" Dia. w/Two Guards (Not shown - see Hydraulic Diagram) 915-2601-139 915-2603-183-1
50 1 Hose, 1/8" Thermal Plastic (Not shown - see Hydraulic Diagram) 23742R 23742R
51 1 Decal, Warning / Pressure Relief Valve (Not shown) See note below 22249 22249
52 1 Decal, Lift Power - On/Off (Not shown) See note below 21494 21494
53 1 Decal, Fold & Barrier Relief Valve Adjustment (Not shown) See note below 33223 33223
54 1 Decal, Manual Instructions - Public (Not shown) See note below 32940 32940
* Apply Locktite
®
Threadlocker Red 271™ or equivalent to the three pump mounting bolts (items 25 and 26) if a blue
nylon patch is not present on the bolts when retrofitting an M268-0117 pump assembly.
Indicates items available for replacement part purposes only. These items are not included with replacement pump
modules.
