Page 29
DWG. NOTES
1) INSERT SOCKET OF LIGHT ASSY THRU TOP KEY
WHILE INSTALLING LIGHT. TIGHTEN SCREWS.
2) HARNESS TO BE TUCKED INSIDE CHANNEL.
3) APPLY LOCTITE
®
THREADLOCKER BLUE 242
®
OR EQUIVALENT
4) APPLY LOCTITE
®
THREADLOCKER RED 271™
OR EQUIVALENT TO ALL #25527 SCREWS.
945-5353
1000-2395A
31062A
945-3448RNW
41
21
11
7
5
1
1
ROLLER ASSY-ARM-TORQUE SHAFT
ASSY-LIGHT-VERTICAL CHANNEL w/BULB
WMT-VERTICAL CHANNEL-REAR-48"
RETAINER-LIFT TITE ROLLER
32408 RUBBER BUMPER-VERT CHAN.
81
92
33689A ASSY-BRIDGE SWITCH W/ HARN/NL/NCL-2
11481 SCREW-#4-40 X 3/8" RD. HD.
10 2
81064-000
6 1 SCREW-1/4-20 X 1" BHCS SS
NOTE:
4
4
5
1
6
NOTE:
1
13
12
NOTE:
3
310603 1 BULB-LIGHT-20W-HALOGEN REFLECTOR
3
11
11
11
2
PART NO.QTY.ITEM DESCRIPTION
"A"
8
9
10
DETAIL A
NOTE:
2
11 3 PIN-PIVOT PARALLEL ARM936-0403
12 3 WASHER-1/2" FLAT/AUTO BK25346
13 3 SCREW-5/16-18 X 3/4" FHS/AUTO-BK25527
7
19537 NUT-#4-40 w/LOCKWASHER
13
12
13
12
Exploded Views and Parts Lists
Vertical Arm Assembly - Rear
Vertical Arm Assembly - Front
PART NO.
QTY.ITEM
DESCRIPTION
DWG. NOTES
1) INSERT SOCKET OF LIGHT ASSY THRU TOP KEY
WHILE INSTALLING LIGHT. TIGHTEN SCREWS.
2) APPLY LOCTITE
®
THREADLOCKER BLUE 242
®
OR EQUIVALENT
3) APPLY LOCTITE
®
THREADLOCKER RED 271™ OR EQUIVALENT TO ALL
#25527 SCREWS.
1
7
5
4
6
8
8
8
NOTE:
1
NOTE:
2
NOTE:
3
3
2
945-5353
1000-2395A
31062A
945-3448FNW
41
21
11
6
5
1
1
ROLLER-ASSY-ARM-TORQUE SHAFT
ASSY-LIGHT-VERTICAL CHANNEL w/BULB
WMT-VERTICAL CHANNEL-FRONT-48"
RETAINER-LIFT TITE ROLLER
81064-000
SCREW-1/4-20 X 1" BHCS SS
7 1 32408 RUBBER BUMPER-VERT CHAN.
8 2 936-0403 PIN-PIVOT PARALLEL
9 2 25346 WASHER-1/2" FLAT/AUTO-BK
10
2 25527 SCREW-5/16-18 X 3/4" FHS/AUTO-BK
310603 1 BULB-LIGHT-20W-HALOGEN REFLECTOR
10
9
10
9
10
9
