U
P
DOWN
3
2
8
1
9
FOL
D
UNF
OLD
3
2
8
2
0
®
Inboard
Outboard
Right
Left
Threshold Strip Switch
33337A
Ground Detect
Microswitch
33434A
Outer Barrier
Raised Microswitch
33434A
IB Occupied
Microswitch
Stow Interlock
Microswitch
IB Occupied &
Stow Interlock Assy.
32514NA
IB Raised Switch
32519A
*Up Microswitch
*Unfold Microswitch
*Threshold / Alarm
Microswitch
*Up & Unfold Microswitch Assy.
975-3121A
*Threshold / Alarm
& Partial Fold
Microswitch Assy.
975-3121A
*Partial Fold
Microswitch
*Note: Mirror image for
left (rear) pump lifts.
Bridging
Microswitch
33689A
Switch and Sensor Locations
