Pump Module Diagram
Pump Mounting Bolts
Apply Loctite
®
Threadlocker Red 271™
or equivalent to the three pump mount-
ing bolts (items 25 and 26) if a blue
nylon patch is not present on the bolts
when retrofitting an M268 pump as-
sembly.
Note: Front pump module shown,
rear pump module mirror image.
