Brother ADS-1100W User Manual

General Information
8
1
9 (Settings)
Lets you access the main settings.
The information icon appears on the Touchscreen when there is an error or maintenance message. For
details, see Error and Maintenance Messages on page 187.
NOTE
This product adopts the font of ARPHIC TECHNOLOGY CO.,LTD.
Basic Operations 1
To operate the screen, use your finger to press the (Settings) or option button directly on the screen.
To display and access all the screen menus or options in a setting, press a or b to scroll through them.
IMPORTANT
DO NOT press the screen with a sharp object, such as a pen or stylus. It may damage the machine.
The following steps show how to change a setting in the machine. In this example, the Document Size setting
in Scan to PC is changed from A4 to Auto.
a Press d or c to display to PC.
b Press to PC.
c Press d or c to display to File.
d Press to File.
e Press Options.
f Press a or b to display Set with Touch Panel.
g Press Set with Touch Panel.
h Press On.
i Press a or b to display Document Size.
j Press Document Size.
k Press a or b to display Auto.
l Press Auto.
NOTE
Press to go back to the previous level.

Brother ADS-1100W Specifications

General

Film scanning	No
Color scanning	Yes
Grayscale levels	256
Input color depth	30 bit
Maximum scan size	210 x 297 mm
Output color depth	24 bit
ADF scan speed (b/w, A4)	16 ppm
Enhanced scan resolution	1200 x 1200 DPI
Optical scanning resolution	600 x 600 DPI
Black/white scanning color modes	Grayscale, Monochrome
Scanner type	ADF scanner
Product color	Black
Scan to	E-mail, FTP, Image, OCR, USB
Sensor type	Dual CIS
Scan drivers	ICA, ISIS, TWAIN, WIA
Internal memory	128 MB
Scan file formats	BMP, JPG, TIFF
Processor frequency	288 MHz
Scanning noise level	47 dB
Daily duty cycle (max)	500 pages
Auto document feeder (ADF) input capacity	20 sheets
ISO A-series sizes (A0...A9)	A4, A5, A6, A7, A8
ISO B-series sizes (B0...B9)	B5, B6, B7
Scanning media types supported	Business Card, Plastic Card
Maximum ISO A-series paper size	A4
Auto Document Feeder (ADF) media weight	52 - 110 g/m²
USB version	2.0
Standard interfaces	USB 1.1, USB 2.0, Wireless LAN
Mac operating systems supported	Mac OS X 10.6 Snow Leopard, Mac OS X 10.7 Lion
Windows operating systems supported	Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows 8, Windows 8 Enterprise, Windows 8 Enterprise x64, Windows 8 Pro, Windows 8 Pro x64, Windows 8 x64, Windows Vista Business, Windows Vista Business x64, Windows Vista Enterprise, Windows Vista Enterprise x64, Windows Vista Home Basic, Windows Vista Home Basic x64, Windows Vista Home Premium, Windows Vista Home Premium x64, Windows Vista Ultimate, Windows Vista Ultimate x64, Windows XP Home, Windows XP Professional
Power supply type	-
Power consumption (off)	0.25 W
Power consumption (standby)	4 W
Power consumption (typical)	14 W
Power consumption (PowerSave)	1.5 W
Package depth	170 mm
Package width	380 mm
Package height	207 mm
Package weight	2500 g
Mobile printing technologies	Brother iPrint & Scan
Custom media width	51 - 215.9 mm
Custom media length	70 - 297 mm

Weight and Dimensions

Depth	103 mm
Width	285 mm
Height	84 mm
Weight	1500 g
