Ill]
Adjusting
home
position.·(1)
1)
Remove the needle
0,
work
clamps
(SEL)@
and
(SER)@).
2) Attach
the
home position standard plate 0
with
the
bolts.
[Adjustment
of
X axis]
[Programmer]
X reference
line
1)
Remove the screw and X-feed bracket cover
(R)
0.
2)
Turn on the
power
switch.
3)
Press
the
P key on the programmer device.
4)
Attach
the
needle
0.
5)
Turn
the
pulley
to
approach
the
needle 0
to
the home position standard plate
0.
6)
Loosen
the
screw
of
the X-home position dog @ and horizontally adjust
the
X-home position dog
@)
so
that
the
needle 0
tip
aligns
with
the home position on the home position standard plate
0.
-50-
