Brother DS-820W User Manual

i
Using the documentation
Thank you for buying a Brother machine! Reading the documentation will help you make the most of your
machine.
Symbols and conventions used in the documentation
The following symbols and conventions are used throughout the documentation.
IMPORTANT IMPORTANT indicates a potentially hazardous situation which, if not avoided, may
result in damage to property or loss of product functionality.
NOTE Notes tell you how you should respond to a situation that may arise or give tips
about how the operation works with other features.
Bold Bold style identifies keys on the machine control panel or computer screen.
Italics Italicized style emphasizes an important point or refers you to a related topic.
Courier New Courier New font identifies the messages shown on the LCD of the machine.
NOTE
• For DSmobile 920DW users: this guide uses DSmobile 820W screen images, unless otherwise indicated.
• If you are using a tablet running Windows
®
, you can make your selections either by tapping the screen or
by clicking with your mouse.

Brother DS-820W Specifications

General

Color scanning	Yes
Duplex scanning	No
Grayscale levels	256
Input color depth	48 bit
Maximum scan size	216 x 812.8 mm
Output color depth	24 bit
Enhanced scan resolution	1200 x 1200 DPI
Optical scanning resolution	600 x 600 DPI
Display	LCD
Scanner type	Sheet-fed scanner
Product color	White
Scan to	E-mail, File, FTP, Image, Memory Card, OCR
Sensor type	CIS
Scan drivers	TWAIN, WIA
Scan file formats	BMP, JPG, PDF, PNG, TIFF
Scanning noise level	50 dB
Daily duty cycle (max)	- pages
Compatible memory cards	SD, SDHC
Standard input capacity	1 sheets
ISO A-series sizes (A0...A9)	A4, A5, A6, A7, A8
ISO B-series sizes (B0...B9)	B5, B6, B7, B8
Scanning media types supported	Business Card, Plain paper
Maximum ISO A-series paper size	A4
USB version	2.0
Standard interfaces	USB 1.1, USB 2.0, Wireless LAN
Mac operating systems supported	Mac OS X 10.6 Snow Leopard, Mac OS X 10.7 Lion, Mac OS X 10.8 Mountain Lion
Windows operating systems supported	Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows 8, Windows 8 Enterprise, Windows 8 Enterprise x64, Windows 8 Pro, Windows 8 Pro x64, Windows 8 x64, Windows Vista Business, Windows Vista Business x64, Windows Vista Enterprise, Windows Vista Enterprise x64, Windows Vista Home Basic, Windows Vista Home Basic x64, Windows Vista Home Premium, Windows Vista Home Premium x64, Windows Vista Ultimate, Windows Vista Ultimate x64, Windows XP Home, Windows XP Home x64, Windows XP Professional, Windows XP Professional x64
Battery type	Built-in battery
Input voltage	5 V
Power supply type	USB
Power consumption (off)	0.05 W
Power consumption (typical)	2.5 W
Package depth	254 mm
Package width	354 mm
Package height	70 mm
Package weight	1180 g
Scan media weight	60 - 105 g/m²
Custom media width	55 - 215.9 mm
Custom media length	90 - 812.8 mm

Weight and Dimensions

Depth	53 mm
Width	308 mm
Height	41 mm
Weight	440 g
