Brother FAX 560 User Manual

12 - 8 TROUBLESHOOTING AND ROUTINE MAINTENANCE
T7BASE-US-FM5.5
WARNING
Just after you have used the machine, the print head is extremely HOT!
Replacing the Print Cartridge
1 Open the top cover by lifting the gray lever on the right side. (See page12-2)
2 Remove the print cartridge
containing the used ribbon and set it
down.
3 Install the new print cartridge, by
inserting the recessed first and
placing the cartridge into its four
holders.
4 Press down on both sides of the top cover to close it securely.
You can save money by purchasing the 2-PK Refill Ribbon Rolls (PC402RF).
Installation instructions will be included. If you handle the print cartridge (frame)
carefully, you can reuse it until it breaks.
Gray Lever
