CHAPTER 2 PCL - 97
6.3.13. Horizontal 1200-dpi image format mode (Raster Graphic Mode 1027)
The printer supports 1200 dpi printing for special image formats in 1200 dpi mode. We recommend that the
installed printer memory is 10 Mbytes or more for 1200 dpi printing.
To set 1200 dpi mode,
1. Set 1200 dpi printing mode by using the following PJL command:
@PJL SET RAS1200MODE = ON
2. Choose PCL mode with the following PJL command:
@PJL ENTER LANGUAGE = PCL
(If you select a mode other than PCL mode, 1200 dpi printing mode cannot be selected.)
The PCL Mode set command for 1200 dpi Image Format is ESC *b1027M. The transfer raster data command
(ESC*b###W) then transfers horizontal 1200 dpi data.
<1200 dpi Graphic Data Compression Format>
This compression format consists of blocks of data 64 dots down the page starting from the leading edge of the
paper.
i.e.: If the graphic data extends over three bands as shown in the following diagram, it transfers the data as
three blocks of data:
ESC*b##W <Block 1> <Block 2> <Block 3>
In mode 1027, the transfer graphic data command byte count does not have a limitation of 32,767 bytes.
The block data is composed as follows:
Position Data Description
0 - 1 Block length n - 2
2 - 3 Horizontal position dots from the left of the page
4 - 5 Vertical position dots from the leading edge of the
page
6 Height dots number of image vertical dots
7 - 8 Width words number of image horizontal 16 bit
words
9 - (n - 1) Compression data compression image data
i.e.: Data is at horizontal position = 256, vertical position = 64, height = 32 dots, width = 100 x 16 bit words
(1600 dots), and compression data is 800 bytes;
ESC*b809W 03h 27h 01h 00h 00h 40h 20h 00h 64h [Data800Byte]
_ _ _ | _ |
a b c d e f
(256, 64)
32
1600
0
64
128
Band 1
Band 2
a: Block length(807)
b: Horizontal position(256)
c: Vertical position(64)
d: Height dots(32)
e: Width words(100)
f: Com
ression ima
e data
0
64
128
192
256
320
Band 1
Band 3
Band 4
Band 2
Band 5
Block 3
Block 2
Block 1
To Next Page
