CHAPTER 3 PCL5C - 17
 PC [pen;]: sets the pen to the default color.
Number of pens in palette Pen number Color
2 ("NP 2;") 0 White
1 Black
4 ("NP 4;") 0 White
1 Black
2 Red
3 Green
8 ("NP 8;") 0 White
1 Black
2 Red
3 Green
4 Yellow
5 Blue
6 Magenta
7 Cyan
** If the number of pens in the palette is over 8, the color is set to black.
6.3. NP (Number of Pens) Command
Command
NP [n;]
NP [;]
Range = 2 ~ 32768
Default value = 8
 This command makes the palette the specified size after the Initialize Set Instruction command or Set PCL
Color Setting command is executed.
 The n value represents the palette number with the value of 2
n
. When it cannot be indicated with the value
of 2
n
, the next value, 2
n+1
is selected.
 When a value over 257 is specified, 256 is selected.
 When a value less than 2 is specified, it is ignored.
 The specified palette can be selected by the Select Pen command. When the value specified by the Select
Pen command is bigger than the palette number specified by this command, the value of the remainder is
used.
6.4. CR (Color Range) Command
Command
CR [....]
Range = - 32768 ~ 32767
Default value is listed below;
R G B
Black reference 0 0 0
White reference 255 255 255
Black reference: specifies the black value (the highest level of density)
White reference: specifies the white value (the lowest level of density)
 This command sets the range for specifying relative color data.
 The value specified by this command is reset to the default value by the CR [;]or IN [;] command.

Brother HL-L9310CDW Specifications

General

Display	LCD
Control type	Touch
Built-in display	Yes
Display diagonal	2.7 \
Market positioning	Business
Maximum duty cycle	80000 pages per month
Recommended duty cycle	- pages per month
Replacement cartridges	TN-910BK TN-910C TN-910M TN-910Y
Number of print cartridges	4
Page description languages	BR-Script 3, PCL 6, PDF 1.7, XPS
Linear (1D) barcodes supported	Codabar, Code 128A, Code 128B, Code 128C, Code 39, Code 93, Facing Identification Mark, GS1 DataBar, ISBN, Interleaved 2 of 5, MSI, POSTNET, UPC-A, UPC-E
Sound power level (standby)	60 dB
Sound power level (printing)	65.5 dB
Sound pressure level (printing)	49 dB
Sound pressure level (quiet mode)	44 dB
N-up printing	2, 4, 9, 16, 25
Print technology	Laser
Maximum resolution	2400 x 600 DPI
Duplex printing mode	Auto/Manual
Time to first page (black, normal)	15 s
Print speed (color, normal quality, A4/US Letter)	31 ppm
Duplex print speed (black, normal quality, A4/US Letter)	14 ppm
Envelopes sizes	10
Custom media width	76.2 - 215.9 mm
Custom media length	127 - 355.6 mm
Paper tray media types	Bond paper, Envelopes, Glossy paper, Labels, Letterhead, Plain paper, Recycled paper
Paper tray media weight	60 - 105 g/m²
Non-ISO print media sizes	Executive (184 x 267mm), Legal (media size), Letter (media size)
ISO A-series sizes (A0...A9)	A4, A5, A6
Multi-purpose tray media types	Bond paper, Glossy paper, Letterhead, Plain paper, Recycled paper
Maximum ISO A-series paper size	A4
Paper tray media weight (imperial)	16 - 28 lbs
Multi-Purpose Tray media weight (imperial)	16 - 43 lbs
Total input capacity	300 sheets
Total output capacity	150 sheets
Maximum input capacity	2380 sheets
Paper tray 1 input capacity	250 sheets
Total number of input trays	1
Multi-Purpose tray input capacity	50 sheets
Authentication method	LDAP, ActiveDirectory, RADIUS
Online services supported	Dropbox, Google Drive
Dimensions (W x D x H) (imperial)	17.4 x 19.1 x 12.3 \
Package depth	603 mm
Package width	642 mm
Package height	578 mm
Package weight	26800 g
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Cabling technology	10/100/1000Base-T(X)
Security algorithms	64-bit WEP, 128-bit WEP, 802.1x RADIUS, AES, EAP-FAST, EAP-TLS, EAP-TTLS, IPSec, LEAP, PEAP, SMTP-AUTH, SNMPv3, SSL/TLS, TKIP, WPA-PSK, WPS
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Mobile printing technologies	Apple AirPrint, Brother iPrint & Scan, Google Cloud Print, Mopria Print Service
Supported network protocols (IPv4)	ARP, RARP, BOOTP, DHCP, APIPA(AutoIP), WINS/NetBIOS name resolution, DNS Resolver, mDNS, LLMNR responder, LPR/ LPD, Custom Raw Port/Port9100, IPP/IPPS, FTP Server, TELNET Server, HTTP/HTTPS server, TFTP client and server, SMTP Client, SNMPv1/v2c/v3, ICMP, Web Services (Print), CIFS client, SNTP client, LDAP
Supported network protocols (IPv6)	NDP, RA, DNS resolver, mDNS, LLMNR responder, LPR/LPD, Custom Raw Port/ Port9100, IPP/IPPS, FTP Server, TELNET Server, HTTP/HTTPS server, TFTP client and server, SMTP Client, SNMPv1/v2c/v3, ICMPv6, Web Services (Print), CIFS Client, SNTP Client, LDAP
USB connector	USB Type-A
USB 2.0 ports quantity	3
Server operating systems supported	Windows Server 2008 R2, Windows Server 2012, Windows Server 2012 R2, Windows Server 2016
Windows operating systems supported	Windows 10, Windows 7, Windows 8
Included cartridge capacity (black)	6500 pages
Power consumption (ready)	70 W
Power consumption (printing)	580 W
Energy Star Typical Electricity Consumption (TEC)	1.8 kWh/week
Sustainability certificates	Blue Angel, ENERGY STAR, Nordic Swan Ecolabel

Weight and Dimensions

Depth	486 mm
Width	441 mm
Height	313 mm
