CHAPTER 4 HP-GL/2 - 38
 The command sets all pen widths to a default of 0.35mm. Hence it should be used before the PW
command.
 Using the command with no parameter defaults the type to 0 (metric) and all pen widths to 0.35mm.
 The unit type is not affected by a DF command.
10 '-Pen Width Unit Selection-
20 WIDTH "LPT1:", 255
30 LPRINT CHR$(27); "E";
40 LPRINT CHR$(27); "%0B";
50 LPRINT "IN;SP1;";
60 'metric
70 LPRINT PA2000,6000;PDPA6000,6000;PU;" 'Default 0.35mm
80 LPRINT "WU0;PA2000,5700;PDPA6000,5700;PU;"'0.35mm
90 LPRINT "WU0;PW1.5;PA2000,5400;PDPA6000,5400;PU;"'1.5mm
100 LPRINT "WU0;PW0.8;PA2000,5100;PDPA6000,5100;PU;"'0.8mm
110 "-relative unit
120 LPRINT "PW;PA2000,4600;PDPA6000,4600;PU;"'Default 0.35mm=4dot
130 LPRINT "IP1000,1000,9000,7000;"
140 LPRINT "WU1;PA2000,4300;PDPA6000,4300;PU;"'300*10/1016=2dot
150 LPRINT "IP1000,1000,5000,4000;"
160 LPRINT "WU1;PA2000,4000;PDPA6000,4000;PU;"'300*5/1016=1dot
170 LPRINT CHR$(27); "%0A";
180 LPRINT CHR$(27); "E";
190 END
<Sample 47>
7.6. Character Plot Instructions
Instruction Function
SD Define Standard Font
AD Define Alternate Font
SS Select Standard Font
SA Select Alternate Font
FI Select Primary Font
FN Select Secondary Font
LB Define Label
DT Define Label Terminator
LO Label Origin
DI Absolute Direction
DR Relative Direction
DV Define Variable Text Path
CP Character Plot
CF Character Fill Mode
SI Set Absolute Character Size
SR Set Relative Character Size
SL Set Character Slant
SB Scalable or Bitmap Fonts
ES Extra Space
TD Transparent Data

Brother HL-L9310CDW Specifications

General

Display	LCD
Control type	Touch
Built-in display	Yes
Display diagonal	2.7 \
Market positioning	Business
Maximum duty cycle	80000 pages per month
Recommended duty cycle	- pages per month
Replacement cartridges	TN-910BK TN-910C TN-910M TN-910Y
Number of print cartridges	4
Page description languages	BR-Script 3, PCL 6, PDF 1.7, XPS
Linear (1D) barcodes supported	Codabar, Code 128A, Code 128B, Code 128C, Code 39, Code 93, Facing Identification Mark, GS1 DataBar, ISBN, Interleaved 2 of 5, MSI, POSTNET, UPC-A, UPC-E
Sound power level (standby)	60 dB
Sound power level (printing)	65.5 dB
Sound pressure level (printing)	49 dB
Sound pressure level (quiet mode)	44 dB
N-up printing	2, 4, 9, 16, 25
Print technology	Laser
Maximum resolution	2400 x 600 DPI
Duplex printing mode	Auto/Manual
Time to first page (black, normal)	15 s
Print speed (color, normal quality, A4/US Letter)	31 ppm
Duplex print speed (black, normal quality, A4/US Letter)	14 ppm
Envelopes sizes	10
Custom media width	76.2 - 215.9 mm
Custom media length	127 - 355.6 mm
Paper tray media types	Bond paper, Envelopes, Glossy paper, Labels, Letterhead, Plain paper, Recycled paper
Paper tray media weight	60 - 105 g/m²
Non-ISO print media sizes	Executive (184 x 267mm), Legal (media size), Letter (media size)
ISO A-series sizes (A0...A9)	A4, A5, A6
Multi-purpose tray media types	Bond paper, Glossy paper, Letterhead, Plain paper, Recycled paper
Maximum ISO A-series paper size	A4
Paper tray media weight (imperial)	16 - 28 lbs
Multi-Purpose Tray media weight (imperial)	16 - 43 lbs
Total input capacity	300 sheets
Total output capacity	150 sheets
Maximum input capacity	2380 sheets
Paper tray 1 input capacity	250 sheets
Total number of input trays	1
Multi-Purpose tray input capacity	50 sheets
Authentication method	LDAP, ActiveDirectory, RADIUS
Online services supported	Dropbox, Google Drive
Dimensions (W x D x H) (imperial)	17.4 x 19.1 x 12.3 \
Package depth	603 mm
Package width	642 mm
Package height	578 mm
Package weight	26800 g
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Cabling technology	10/100/1000Base-T(X)
Security algorithms	64-bit WEP, 128-bit WEP, 802.1x RADIUS, AES, EAP-FAST, EAP-TLS, EAP-TTLS, IPSec, LEAP, PEAP, SMTP-AUTH, SNMPv3, SSL/TLS, TKIP, WPA-PSK, WPS
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Mobile printing technologies	Apple AirPrint, Brother iPrint & Scan, Google Cloud Print, Mopria Print Service
Supported network protocols (IPv4)	ARP, RARP, BOOTP, DHCP, APIPA(AutoIP), WINS/NetBIOS name resolution, DNS Resolver, mDNS, LLMNR responder, LPR/ LPD, Custom Raw Port/Port9100, IPP/IPPS, FTP Server, TELNET Server, HTTP/HTTPS server, TFTP client and server, SMTP Client, SNMPv1/v2c/v3, ICMP, Web Services (Print), CIFS client, SNTP client, LDAP
Supported network protocols (IPv6)	NDP, RA, DNS resolver, mDNS, LLMNR responder, LPR/LPD, Custom Raw Port/ Port9100, IPP/IPPS, FTP Server, TELNET Server, HTTP/HTTPS server, TFTP client and server, SMTP Client, SNMPv1/v2c/v3, ICMPv6, Web Services (Print), CIFS Client, SNTP Client, LDAP
USB connector	USB Type-A
USB 2.0 ports quantity	3
Server operating systems supported	Windows Server 2008 R2, Windows Server 2012, Windows Server 2012 R2, Windows Server 2016
Windows operating systems supported	Windows 10, Windows 7, Windows 8
Included cartridge capacity (black)	6500 pages
Power consumption (ready)	70 W
Power consumption (printing)	580 W
Energy Star Typical Electricity Consumption (TEC)	1.8 kWh/week
Sustainability certificates	Blue Angel, ENERGY STAR, Nordic Swan Ecolabel

Weight and Dimensions

Depth	486 mm
Width	441 mm
Height	313 mm
