CHAPTER 3 PCL5C - 16
6. HP-GL/2
A few HP-GL/2 commands are added for the HL-2400C/Ce, HL-3400CN, HL-2600CN, HL-3450CN, HL-
2700CN, HL-
4040CN/4050CDN/4070CDW/3070CW/3075CW/4140CN/4150CDN/4570CDW/3170CDW/L8250CDN/L835
0CDW/L9200CDW/L9300CDW color laser printer, and the features of some existing commands are also
expanded.
The new or revised HP-GL/2 commands as follows are described in this chapter;
 Initialize Set Instruction (IN) - resets all programmable functions to their default settings
 Pen Color (PC) - changes the palette colors
 Number of Pens (NP) - changes the palette size
 Color Range (CR) - sets the range for specifying relative color data
For the basic commands of HP-GL/2, refer to 'Chapter 8 HP-GL/2 Graphics Language'.
6.1. IN (Initialize Set Instruction) Command
Command
IN [;]
This command returns the graphics mode to initial conditions. It initializes the parameters listed on Page.9 of
'Chapter 8 HP-GL/2' and also those shown below.
Function Equivalent
Instruction
Condition
Number of Pens NP 8
Color Range CR Black reference (red, green, blue) ----> 0
White reference (red, green, blue) ----> 255
This command also initializes the parameters of the palette as follows;
Palette No.(Pen No.) Color
0 White
1 Black
2 Red
3 Green
4 Yellow
5 Blue
6 Magenta
7 Cyan
6.2. PC (Pen Color) Command
Command
PC [pen, red, green, blue]
PC [pen;]
PC [;]
This command changes the pen colors in the palette and sets the colors of all pens to their default settings.
 pen: represents the palette number specified by this command. It ignores the command if it is out of
the range of the specified parameter.
 red, green, blue: specifies the color. The range of the specified value is determined by the CR command.
Default range is 0 ~ 255.
 PC [;]: initializes all palettes.

Brother HL-L9310CDW Specifications

General

Display	LCD
Control type	Touch
Built-in display	Yes
Display diagonal	2.7 \
Market positioning	Business
Maximum duty cycle	80000 pages per month
Recommended duty cycle	- pages per month
Replacement cartridges	TN-910BK TN-910C TN-910M TN-910Y
Number of print cartridges	4
Page description languages	BR-Script 3, PCL 6, PDF 1.7, XPS
Linear (1D) barcodes supported	Codabar, Code 128A, Code 128B, Code 128C, Code 39, Code 93, Facing Identification Mark, GS1 DataBar, ISBN, Interleaved 2 of 5, MSI, POSTNET, UPC-A, UPC-E
Sound power level (standby)	60 dB
Sound power level (printing)	65.5 dB
Sound pressure level (printing)	49 dB
Sound pressure level (quiet mode)	44 dB
N-up printing	2, 4, 9, 16, 25
Print technology	Laser
Maximum resolution	2400 x 600 DPI
Duplex printing mode	Auto/Manual
Time to first page (black, normal)	15 s
Print speed (color, normal quality, A4/US Letter)	31 ppm
Duplex print speed (black, normal quality, A4/US Letter)	14 ppm
Envelopes sizes	10
Custom media width	76.2 - 215.9 mm
Custom media length	127 - 355.6 mm
Paper tray media types	Bond paper, Envelopes, Glossy paper, Labels, Letterhead, Plain paper, Recycled paper
Paper tray media weight	60 - 105 g/m²
Non-ISO print media sizes	Executive (184 x 267mm), Legal (media size), Letter (media size)
ISO A-series sizes (A0...A9)	A4, A5, A6
Multi-purpose tray media types	Bond paper, Glossy paper, Letterhead, Plain paper, Recycled paper
Maximum ISO A-series paper size	A4
Paper tray media weight (imperial)	16 - 28 lbs
Multi-Purpose Tray media weight (imperial)	16 - 43 lbs
Total input capacity	300 sheets
Total output capacity	150 sheets
Maximum input capacity	2380 sheets
Paper tray 1 input capacity	250 sheets
Total number of input trays	1
Multi-Purpose tray input capacity	50 sheets
Authentication method	LDAP, ActiveDirectory, RADIUS
Online services supported	Dropbox, Google Drive
Dimensions (W x D x H) (imperial)	17.4 x 19.1 x 12.3 \
Package depth	603 mm
Package width	642 mm
Package height	578 mm
Package weight	26800 g
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Cabling technology	10/100/1000Base-T(X)
Security algorithms	64-bit WEP, 128-bit WEP, 802.1x RADIUS, AES, EAP-FAST, EAP-TLS, EAP-TTLS, IPSec, LEAP, PEAP, SMTP-AUTH, SNMPv3, SSL/TLS, TKIP, WPA-PSK, WPS
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Mobile printing technologies	Apple AirPrint, Brother iPrint & Scan, Google Cloud Print, Mopria Print Service
Supported network protocols (IPv4)	ARP, RARP, BOOTP, DHCP, APIPA(AutoIP), WINS/NetBIOS name resolution, DNS Resolver, mDNS, LLMNR responder, LPR/ LPD, Custom Raw Port/Port9100, IPP/IPPS, FTP Server, TELNET Server, HTTP/HTTPS server, TFTP client and server, SMTP Client, SNMPv1/v2c/v3, ICMP, Web Services (Print), CIFS client, SNTP client, LDAP
Supported network protocols (IPv6)	NDP, RA, DNS resolver, mDNS, LLMNR responder, LPR/LPD, Custom Raw Port/ Port9100, IPP/IPPS, FTP Server, TELNET Server, HTTP/HTTPS server, TFTP client and server, SMTP Client, SNMPv1/v2c/v3, ICMPv6, Web Services (Print), CIFS Client, SNTP Client, LDAP
USB connector	USB Type-A
USB 2.0 ports quantity	3
Server operating systems supported	Windows Server 2008 R2, Windows Server 2012, Windows Server 2012 R2, Windows Server 2016
Windows operating systems supported	Windows 10, Windows 7, Windows 8
Included cartridge capacity (black)	6500 pages
Power consumption (ready)	70 W
Power consumption (printing)	580 W
Energy Star Typical Electricity Consumption (TEC)	1.8 kWh/week
Sustainability certificates	Blue Angel, ENERGY STAR, Nordic Swan Ecolabel

Weight and Dimensions

Depth	486 mm
Width	441 mm
Height	313 mm
