CHAPTER 9 HP-GL - 13
10 '*** CIEX1 ***
20 LPRINT "IN;SP1;IP2650,1325,7650,6325;"
30 LPRINT "SC-100,100,-100,100;"
40 LPRINT "PA-60,50;CI40,45;"
50 LPRINT "PA60,50;CI40,30;"
60 LPRINT "PA-60,-50;CI40,15;"
70 LPRINT "PA60,-50;CI40,5;"
80 END
<Sample 65>
10 '*** CIEX2 ***
20 LPRINT "IN;SP1;IP2650,1325,8650,7325;"
30 LPRINT "SC0,170,0,170;"
40 LPRINT "PA100,100;LT;CI10,5;LT0;CI-20,5;LT1;CI30,5;"
50 LPRINT "LT2;CI-40,5;LT3;CI50,5;LT4;CI-
60,5;LT5;CI70,5;LT6;CI80,5;"
60 END
<Sample 66>
10 '*** CIEX3 ***
20 LPRINT "IN;SP1;IP2650,1325,7650,6325;"
30 LPRINT "SC-1000,1000,-1000,1000;"
40 LPRINT "PA-800,800;"
50 GOSUB 130
60 LPRINT "PA200,800;"
70 GOSUB 130
80 LPRINT "PA-800,-200;"
90 GOSUB 130
100 LPRINT"PA200,-200;"
110 GOSUB 130
120 END
130 LPRINT "CI70;PR600,0;CI70;PR-300,-300;CI250;"
140 LPRINT "PR-300,-300;CI70;PR600,0;CI70;"
150 RETURN
<Sample 67>
3.4. The polygon Group
Instruction Function
EA Edge Absolute Rectangle
ER Edge Relative Rectangle
EW Edge Wedge
RA Fill Absolute Rectangle
RR Fill Relative Rectangle
WG Fill Wedge
EA - Edge rectangle absolute
EA X, Y[;]
X ; X coordinate of opposite angle for the rectangle
Y ; Y coordinate of opposite angle for the rectangle
 X and Y coordinates are absolute coordinates in user units or graphics units.
 Plots the rectangle formed by the current position and the opposite angle specified by X and Y.
 After plotting the cursor returns to its point of origin.
 Plotting is performed whether the pen is up or down.
 When scaling has been performed, the rectangle is plotted in user units.
 Also, when scaling has been performed, the values for X and Y are real numbers.
 When there is no scaling, the rectangle is plotted in graphics units.

Brother HL-L9310CDW Specifications

General

Display	LCD
Control type	Touch
Built-in display	Yes
Display diagonal	2.7 \
Market positioning	Business
Maximum duty cycle	80000 pages per month
Recommended duty cycle	- pages per month
Replacement cartridges	TN-910BK TN-910C TN-910M TN-910Y
Number of print cartridges	4
Page description languages	BR-Script 3, PCL 6, PDF 1.7, XPS
Linear (1D) barcodes supported	Codabar, Code 128A, Code 128B, Code 128C, Code 39, Code 93, Facing Identification Mark, GS1 DataBar, ISBN, Interleaved 2 of 5, MSI, POSTNET, UPC-A, UPC-E
Sound power level (standby)	60 dB
Sound power level (printing)	65.5 dB
Sound pressure level (printing)	49 dB
Sound pressure level (quiet mode)	44 dB
N-up printing	2, 4, 9, 16, 25
Print technology	Laser
Maximum resolution	2400 x 600 DPI
Duplex printing mode	Auto/Manual
Time to first page (black, normal)	15 s
Print speed (color, normal quality, A4/US Letter)	31 ppm
Duplex print speed (black, normal quality, A4/US Letter)	14 ppm
Envelopes sizes	10
Custom media width	76.2 - 215.9 mm
Custom media length	127 - 355.6 mm
Paper tray media types	Bond paper, Envelopes, Glossy paper, Labels, Letterhead, Plain paper, Recycled paper
Paper tray media weight	60 - 105 g/m²
Non-ISO print media sizes	Executive (184 x 267mm), Legal (media size), Letter (media size)
ISO A-series sizes (A0...A9)	A4, A5, A6
Multi-purpose tray media types	Bond paper, Glossy paper, Letterhead, Plain paper, Recycled paper
Maximum ISO A-series paper size	A4
Paper tray media weight (imperial)	16 - 28 lbs
Multi-Purpose Tray media weight (imperial)	16 - 43 lbs
Total input capacity	300 sheets
Total output capacity	150 sheets
Maximum input capacity	2380 sheets
Paper tray 1 input capacity	250 sheets
Total number of input trays	1
Multi-Purpose tray input capacity	50 sheets
Authentication method	LDAP, ActiveDirectory, RADIUS
Online services supported	Dropbox, Google Drive
Dimensions (W x D x H) (imperial)	17.4 x 19.1 x 12.3 \
Package depth	603 mm
Package width	642 mm
Package height	578 mm
Package weight	26800 g
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Cabling technology	10/100/1000Base-T(X)
Security algorithms	64-bit WEP, 128-bit WEP, 802.1x RADIUS, AES, EAP-FAST, EAP-TLS, EAP-TTLS, IPSec, LEAP, PEAP, SMTP-AUTH, SNMPv3, SSL/TLS, TKIP, WPA-PSK, WPS
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Mobile printing technologies	Apple AirPrint, Brother iPrint & Scan, Google Cloud Print, Mopria Print Service
Supported network protocols (IPv4)	ARP, RARP, BOOTP, DHCP, APIPA(AutoIP), WINS/NetBIOS name resolution, DNS Resolver, mDNS, LLMNR responder, LPR/ LPD, Custom Raw Port/Port9100, IPP/IPPS, FTP Server, TELNET Server, HTTP/HTTPS server, TFTP client and server, SMTP Client, SNMPv1/v2c/v3, ICMP, Web Services (Print), CIFS client, SNTP client, LDAP
Supported network protocols (IPv6)	NDP, RA, DNS resolver, mDNS, LLMNR responder, LPR/LPD, Custom Raw Port/ Port9100, IPP/IPPS, FTP Server, TELNET Server, HTTP/HTTPS server, TFTP client and server, SMTP Client, SNMPv1/v2c/v3, ICMPv6, Web Services (Print), CIFS Client, SNTP Client, LDAP
USB connector	USB Type-A
USB 2.0 ports quantity	3
Server operating systems supported	Windows Server 2008 R2, Windows Server 2012, Windows Server 2012 R2, Windows Server 2016
Windows operating systems supported	Windows 10, Windows 7, Windows 8
Included cartridge capacity (black)	6500 pages
Power consumption (ready)	70 W
Power consumption (printing)	580 W
Energy Star Typical Electricity Consumption (TEC)	1.8 kWh/week
Sustainability certificates	Blue Angel, ENERGY STAR, Nordic Swan Ecolabel

Weight and Dimensions

Depth	486 mm
Width	441 mm
Height	313 mm
