Brother HL-T4000DW User Manual

Home > Mobile/Web Connect > Brother Web Connect > Conditions for Using Brother Web
Connect > Configure the Proxy Server Settings Using Web Based Management
Configure the Proxy Server Settings Using Web Based Management
If your network uses a proxy server, the following proxy server information must be configured using Web
Based Management:
• Proxy server address
• Port number
• User Name
• Password
We recommend Microsoft Internet Explorer 11 and Microsoft Edge for Windows, and Safari 10/11 for Mac.
Make sure that JavaScript and Cookies are always enabled in whichever browser you use.
1. Start your web browser.
2. Type "https://machine's IP address" in your browser's address bar (where "machine's IP address" is the
machine's IP address).
For example:
https://192.168.1.2
3. If the machine prompts you for a password, type it, and then click
.
4. Click the Network tab.
5. Click the Protocol menu in the left navigation bar.
6. Make sure the Proxy check box is selected, and then click Submit.
7. In the Proxy field, click Advanced Settings.
8. Enter the proxy server information.
9. Click Submit.
Related Information
• Conditions for Using Brother Web Connect
206

Brother HL-T4000DW Specifications

General

Color	Yes
Printing colors	Black, Cyan, Magenta, Yellow
Maximum duty cycle	30000 pages per month
Recommended duty cycle	250 - 2000 pages per month
Number of print cartridges	4
Page description languages	-
Maximum resolution	4200 x 1200 DPI
Print speed (ISO/IEC 24734) mono	22 ipm
Print speed (ISO/IEC 24734) color	20 ipm
Print speed (black, normal quality, A3)	35 ppm
Print speed (color, normal quality, A3)	27 ppm
Print speed (black, normal quality, A4/US Letter)	- ppm
Paper input type	Paper tray
Total input capacity	250 sheets
Total output capacity	100 sheets
Total number of input trays	1
Sound pressure level (printing)	50 dB
Envelopes sizes	C5, Com-10, DL, Monarch
Paper tray media types	Photo paper, Plain paper
Non-ISO print media sizes	Folio (media size), Index card, Legal (media size)
ISO A-series sizes (A0...A9)	A3, A4, A5, A6
JIS B-series sizes (B0...B9)	B5, B6
Photo paper sizes (imperial)	3.5x5, 4x6, 5x7, 5x8 \
Maximum ISO A-series paper size	A3
Wi-Fi standards	802.11b, 802.11g
Standard interfaces	Ethernet, USB 2.0, Wireless LAN
Display	TFT
Control type	Touch
Product color	Black
Display diagonal	2.7 \
Market positioning	Business
Power consumption (off)	0.04 W
Power consumption (ready)	5 W
Power consumption (standby)	1.2 W
Power consumption (printing)	20 W
Mac operating systems supported	Mac OS X 10.11 El Capitan, Mac OS X 10.12 Sierra, Mac OS X 10.13 High Sierra
Server operating systems supported	Windows Server 2008, Windows Server 2008 R2, Windows Server 2012, Windows Server 2012 R2, Windows Server 2016
Windows operating systems supported	Windows 10, Windows 7, Windows 8, Windows 8.1
Sustainability certificates	ENERGY STAR
Operating temperature (T-T)	10 - 35 °C

Weight and Dimensions

Depth	477 mm
Width	575 mm
Height	310 mm
