Brother ql-560 User Manual

Maintenance and Troubleshooting
16
Items Specifications
Display LED lamp (green)
Print
Printing
method
Direct thermal printing via thermal head
Speed of
printing
Max. 90 mm/sec, Max. 56 labels/min. (Standard Address Labels)
Print head 300 dpi/720 dot
Max. printing
width
59 mm
Min. printing
length
25.4 mm
Cutter Automatic cutter
Button ON/OFF button ( ), FEED button, CUT button
Interface USB
Power supply 220-240V AC 50/60Hz 0.9 A
Size 146 mm (W) × 196 mm (D) × 152 mm (H)
Weight Approx. 1.3 kg (Without DK Rolls)
Operating temperature 10°C to 35°C
Operating humidity 20% to 80% (without condensation)
Product Specifications

Brother ql-560 Specifications

General

Print Technology	Direct Thermal
Print Resolution	300 dpi
Cutter	Automatic
Interface	USB
Operating System Compatibility	Windows, Mac
Power Supply	AC Adapter
Max Print Width	62 mm
Max Label Width	62 mm
Max Label Length	3 ft
Print Speed	50 mm/s
Compatible Label Types	Die-cut labels, Continuous tapes
