Canon imagePROGRAF iPF815 Service Manual

Chapter 5
5-1
5.1 Periodic Replacement Parts
5.1.1 Periodic Replacement Parts
0012-6595
5.2 Consumable Parts
5.2.1 Consumable Parts
0020-5716
- Maintenance Kit
After supplies have been replaced, execute [INITIALIZE] > [PARTS COUNTER] > [PARTS xx] in service mode to initialize (clear) the parts counter information.
Level Periodic Replacement Part
User None
Service Personnel None
Consumables Service Mode
Name Part number Q'ty
Life
sheets/A0
PARTS xx COUNTER x States (Error Code)
Service WASTE INK BOX UNIT (L) QM3-4814 1 25000 A1 A OK/W1/E146-4001
WASTE INK ABSORBER UNIT QL2-2822 3 25000 A2/A3/A4
PLATEN FAN DUCT UNIT QM3-4816 1 25000 A5
PLATEN SUCTION FAN UNIT QM3-4827 1
WASTE INK BOX UNIT QM3-4828 1
CARRIAGE UNIT QM3-4835 1 25000 D1/D2/D3 D OK/W1/W2
MOUNT, MULTI SENSOR
REFERENCE
QL2-2840 1 25000 D1/D2/D3/D5
SCALE, LINEAR QC3-1889 1 25000 D2
TUBE UNIT QM3-4834 1 25000 D4 D OK/W1/E144-4047
MULTI SENSOR UNIT QM3-5240 1 25000 D5 D OK/W1/W2
PURGE UNIT QM3-4847 1 25000 H1/H2 H OK/W1/E141-4046
WASTE INK RECEPTACLE UNIT QM3-4912 1 25000 H2 H OK/W1/E144-404F
HEAD MANAGEMENT SENSOR
UNIT
QM3-4844 1 25000 K1 K OK/W1/E194-404A
MOTOR, DC BRUSHLESS QK1-5211 1 25000 M1 M OK/W1/W2
FEED MOTOR ASS'Y QM3-5246 1 50000 P1 P OK/W1/W2
ROLLER, PICK-UP QC3-0208 1 25000 S1 S OK/W1/W2
MIST FAN UNIT QM3-4846 2 50000 V1 V OK/W1/E146-4001
CUTTER QM3-4873 1 100000 Y1 Y OK/W1/W2
User See "Product Overview> Features> Consumables"
Kit name Parts number Life Counter name
MAINTENANCE KIT A QY6-1328 25000 A
MAINTENANCE KIT D QY6-1329 25000 D

Canon imagePROGRAF iPF815 Specifications

General

Color	Yes
Printing colors	Black, Cyan, Magenta, Pigment matte black, Yellow
Maximum resolution	2400 x 1200 DPI
Number of print cartridges	5
Package weight	301200 g
Bundled software	Printer Driver Extra Kit for Windows/Mac (Free Layout, Color imageRUNNER Enlargement Copy, Advanced Preview), Print Plug-in for Microsoft Word/Excel/PowerPoint for Windows, Digital Photo Front-Access for Windows, PosterArtist Lite for Windows
Media thickness	0.07 - 0.8 mm
Roll top margin	3 mm
Maximum print size	-
Maximum roll length	18 m
Maximum roll diameter	150 mm
ISO A-series sizes (A0...A9)	A0, A1
ISO B-series sizes (B0...B9)	B0, B2
Electromagnetic compatibility	RoHS Directive, WEEE, Executive Order (USA)
Power requirements	AC 100 - 240V, 50/60Hz
Power consumption (off)	1 W
Power consumption (standby)	6 W
Power consumption (typical)	190 W
Certification	UL (USA), C-UL (Canada), S mark (Argentina), CE mark (EN60950, EN55022 classB, EN61000-3-2, EN-61000-3-3, EN55024) (EU), CB certification (Others), FCC Class B (USA), IC Class B (Canada)
Storage media	HDD
Internal storage capacity	160 GB
Sound power level (standby)	35 dB
Sound pressure level (printing)	52 dB
USB connector	USB Type-A
USB 2.0 ports quantity	1
Ethernet LAN data rates	10/100Base-T/TX Mbit/s
Sustainability certificates	ENERGY STAR
Operating temperature (T-T)	15 - 30 °C
Operating relative humidity (H-H)	10 - 80 %
Compatible operating systems	Windows XP (32/64 bit), Server 2003 (32/64 bit), Server 2008 (32/64 bit), Windows Vista (32/64 bit), Windows 7 (32/64 bit); Macintosh OS X 10.3.9 - 10.6 (32 bit), OS X 10.5 - 10.6 (64 bit)

Weight and Dimensions

Dimensions (WxDxH)	1892 x 975.4 x 1143 mm
