Canon imagePROGRAF iPF815 Service Manual

Chapter 1
1-8
1.3 Product Specifications
1.3.1 Product Specifications
0025-9235
Type Bubble jet large-sized paper printer (stand model)
Feeding system Roll media: Manual (front loading)
Cut sheet: Paper tray (front loading)
Feeding capacity - Roll media
1 roll madia/Outer diameter of roll: 150 mm or less
- Cut sheet
1 sheet
Delivery method Forward delivery, face up
Sheet delivery capability 1 sheet (using the outout stacker of the stand)
However, 20 sheets can be stacked according to the condition (using
wheeled output stacker).
Cutter Automatic cross-cutter (round blade)
Type of media Plain Paper, Plain Paper (High Quality), Plain Paper (High Grade),
Coated Paper, Heavyweight Coated Paper, Premium Matte Paper,
Glossy Photo Paper, Semi-Glossy Photo Paper, Backlit Film, Backprint
Film, Flame-Resistant Cloth, Fine Art Photo, Fine Art Heavyweight
Photo, Fine Art Textured, Canvas Matte, Premium Coated Paper,
Graphic Canvas, Durable Backlit Film, Durable Banner, Matt Coated
Paper, Extra Matt Coated Paper, Opaque Paper, Hi Res Graphic Paper,
Prem Art Paper Embossed, Prem Art Paper Smooth, Hi Res Barrier
Paper, Scrim Banner, Uni Opaque Backlit Film, Roll-Up Film, Water
Res Art Canvas, Adhesive Matt Vinyl Stretch
Supported thickness 0.07mm to 0.8mm
Media size (Roll media) Width: 254mm (10") to 1118mm (44")
Length: 203mm (8") to 18m (709")
* Outer diameter of roll :150mm or less
* The maximum amount of length may vary by the using operating
system or the applications.
Media size (Cut sheet) Width: 203mm (8") to 1118mm (44")
Length: 203mm (8") to 1600mm (63")
Printable area (Roll media) Internal area, excluding a 3-mm top, bottom and left and right margins.
* The printable area may vary with each type of paper media used.
Printable area (Cut sheet) Internal area, excluding a 3-mm top margin, a 23-mm bottom margin and
3-mm left and right margins.
* The printable area may vary with each type of paper media used.
Printing recommendation area
(Roll media)
Internal area, excluding a 20-mm top margin, a 5-mm bottom margin and
5-mm left and right margins.
Printing recommendation area
(Cut sheet)
Internal area, excluding a 20-mm top margin, a 23-mm bottom margin
and 5-mm left and right margins.
Borderless printing * Roll media only
width: 254mm(10"), 355.6mm(14"), 431.8mm(17"), 515mm, 594mm,
609.6mm(24"), 841mm, 914.4mm(36"), 1030mm, 1066.8mm(42")
Memory 32GB
Increase of memory: none
Firmware Flash ROM (update from USB or Ethernet)
- Printer description language
GARO (Graphic Arts language with Raster Operation), HP-GL/2, HP-
RTL
Hard disk drive 160GB (2.5inch, 5400rpm, S-ATA I/F)
Emulation None
Interface USB 2.0 Hi-Speed
Network (10BASE-T/100BASE-TX)
Operation panel LCD (160 X 128 dots), 12 keys, 5 LEDs
- Panel language
English
- Message language
English, German, French, Italian, Spanish, Chinese, Korean, Russianand
and Japanese
Printhead/Ink Tank type Printhead and separate ink tanks
Printhead PF-03
Structure: Integrated six-color assembly
Number of nozzles: 2,560 for each color
Ink tank PFI-301 BK/MBK/C/M/Y
PFI-701 BK/MBK/C/M/Y
Ink type: Pigment ink (MBK), Dye ink (BK, C, M, Y)
Ink tank capacity: PFI-303 330 ml, PFI-703 700 ml
Detection functions (Cover
system)
Cover open/closed detection: Yes
Ink tank cover open/closed detection: Yes
Detection functions (Ink passage
system)
Ink tank presence/absence detection: Yes
Remaining ink level detection: Yes
Maintenance cartridge presence/absence detection: Yes
Used ink tank full detection: Yes
Valve open/closed detection: Yes

Canon imagePROGRAF iPF815 Specifications

General

Color	Yes
Printing colors	Black, Cyan, Magenta, Pigment matte black, Yellow
Maximum resolution	2400 x 1200 DPI
Number of print cartridges	5
Package weight	301200 g
Bundled software	Printer Driver Extra Kit for Windows/Mac (Free Layout, Color imageRUNNER Enlargement Copy, Advanced Preview), Print Plug-in for Microsoft Word/Excel/PowerPoint for Windows, Digital Photo Front-Access for Windows, PosterArtist Lite for Windows
Media thickness	0.07 - 0.8 mm
Roll top margin	3 mm
Maximum print size	-
Maximum roll length	18 m
Maximum roll diameter	150 mm
ISO A-series sizes (A0...A9)	A0, A1
ISO B-series sizes (B0...B9)	B0, B2
Electromagnetic compatibility	RoHS Directive, WEEE, Executive Order (USA)
Power requirements	AC 100 - 240V, 50/60Hz
Power consumption (off)	1 W
Power consumption (standby)	6 W
Power consumption (typical)	190 W
Certification	UL (USA), C-UL (Canada), S mark (Argentina), CE mark (EN60950, EN55022 classB, EN61000-3-2, EN-61000-3-3, EN55024) (EU), CB certification (Others), FCC Class B (USA), IC Class B (Canada)
Storage media	HDD
Internal storage capacity	160 GB
Sound power level (standby)	35 dB
Sound pressure level (printing)	52 dB
USB connector	USB Type-A
USB 2.0 ports quantity	1
Ethernet LAN data rates	10/100Base-T/TX Mbit/s
Sustainability certificates	ENERGY STAR
Operating temperature (T-T)	15 - 30 °C
Operating relative humidity (H-H)	10 - 80 %
Compatible operating systems	Windows XP (32/64 bit), Server 2003 (32/64 bit), Server 2008 (32/64 bit), Windows Vista (32/64 bit), Windows 7 (32/64 bit); Macintosh OS X 10.3.9 - 10.6 (32 bit), OS X 10.5 - 10.6 (64 bit)

Weight and Dimensions

Dimensions (WxDxH)	1892 x 975.4 x 1143 mm
