Canon imagePROGRAF iPF815 Service Manual

Chapter 7
7-2
7.1.2 Map of the Service Mode
0020-5734
The hierarchy of menus and parameters in the Service Mode is as shown below.
T-7-1
First Level Second Level Third Level Fourth Level Fifth Level Sixth Level
DISPLAY PRINTINF YES/NO : Select YES to execute
print
SYSTEM S/N
TYPE
LF TYPE
TMP
SIZE LF
SIZE LF
SIZE CR
SIZE CR
HEAD S/N
LOT
INK C
---
BK
WARNING 1
---
20
ERROR 1
---
20
INK CHECK 0 0 0 0 0
I/O DISPLAY I/O DISPLAY 1
I/O DISPLAY 2
ADJUST PRINT PATTERN NOZZLE 1 : Press the [OK] button to
execute
OPTICAL AXIS : Press the [OK] button to
execute
LF TUNING
LF TUNING 2
HEAD ADJ. MANUAL HEAD ADJ DETAIL : Press the [OK]
button to execute
BASIC : Press the [OK]
button to execute
ADJ. SETTING A A-1 : Adjustment value
entry
---
A-48 : Adjustment value
entry
---
F F-1 : Adjustment value
entry
F-2 : Adjustment value
entry
SAVE SETTINGS YES/NO
RESET SETTINGS YES/NO
NOZZLE CHK POS. YES/NO
GAP CALIB. YES/NO
CHANGE LF TYPE 0/1
CR REG EXECUTE YES/NO
RESET YES/NO
REPLACE CUTTER YES/NO

Canon imagePROGRAF iPF815 Specifications

General

Color	Yes
Printing colors	Black, Cyan, Magenta, Pigment matte black, Yellow
Maximum resolution	2400 x 1200 DPI
Number of print cartridges	5
Package weight	301200 g
Bundled software	Printer Driver Extra Kit for Windows/Mac (Free Layout, Color imageRUNNER Enlargement Copy, Advanced Preview), Print Plug-in for Microsoft Word/Excel/PowerPoint for Windows, Digital Photo Front-Access for Windows, PosterArtist Lite for Windows
Media thickness	0.07 - 0.8 mm
Roll top margin	3 mm
Maximum print size	-
Maximum roll length	18 m
Maximum roll diameter	150 mm
ISO A-series sizes (A0...A9)	A0, A1
ISO B-series sizes (B0...B9)	B0, B2
Electromagnetic compatibility	RoHS Directive, WEEE, Executive Order (USA)
Power requirements	AC 100 - 240V, 50/60Hz
Power consumption (off)	1 W
Power consumption (standby)	6 W
Power consumption (typical)	190 W
Certification	UL (USA), C-UL (Canada), S mark (Argentina), CE mark (EN60950, EN55022 classB, EN61000-3-2, EN-61000-3-3, EN55024) (EU), CB certification (Others), FCC Class B (USA), IC Class B (Canada)
Storage media	HDD
Internal storage capacity	160 GB
Sound power level (standby)	35 dB
Sound pressure level (printing)	52 dB
USB connector	USB Type-A
USB 2.0 ports quantity	1
Ethernet LAN data rates	10/100Base-T/TX Mbit/s
Sustainability certificates	ENERGY STAR
Operating temperature (T-T)	15 - 30 °C
Operating relative humidity (H-H)	10 - 80 %
Compatible operating systems	Windows XP (32/64 bit), Server 2003 (32/64 bit), Server 2008 (32/64 bit), Windows Vista (32/64 bit), Windows 7 (32/64 bit); Macintosh OS X 10.3.9 - 10.6 (32 bit), OS X 10.5 - 10.6 (64 bit)

Weight and Dimensions

Dimensions (WxDxH)	1892 x 975.4 x 1143 mm
