Load the print head alignment sheet WITH THE PRINTED SIDE FACING DOWN and align the mark
on the bottom right corner of the sheet with the alignment mark .
10.
Close the document cover gently, then select OK.
The printer starts scanning the print head alignment sheet, and the print head position will be adjusted
automatically.
Important
• Do not open the document cover or move the print head alignment sheet on the platen glass until
adjusting the print head position is complete.
• If the error message appears on the LCD, select OK to release the error, then take appropriate
action.
An Error Occurs
11.
When the completion message appears, select OK.
Remove the print head alignment sheet on the platen glass.
Note
• If the print results are still not satisfactory after adjusting the print head position as described above,
adjust the print head position manually from the computer.
• For Windows:
Adjusting Print Head Position
• For Mac OS:
Adjusting Print Head Position
• To print and check the current head position adjustment values, select Print the head alignment value
on the Maintenance screen.
83

Canon PIXMA TS5000 Series Specifications

General

Printer Type	All-In-One
Print Resolution	4800 x 1200 dpi
Print Technology	Inkjet
Scan Type	Flatbed
Scanner Resolution	1200 x 2400 dpi
Borderless Printing	Yes
Mobile Printing	Yes
Weight	5.5 kg
Colour Print Speed	9 ipm
Copy Resolution	600 x 1200 dpi
Connectivity	USB, Wi-Fi
Compatible Ink	PGI-570, CLI-571
Paper Sizes	A4, A5, B5, Letter, Legal, Envelopes (DL, COM10), 13x18cm, 10x15cm
Display	3.0 inch LCD
