Canon VB-H43 User Manual

[SSL/TLS] Setting HTTP Communication Encryption
77
5
Setting Page
(6) [Display Server Certificate Details]
Click [Exec] to view the details of the certificate.
(7) [Display Self CA Certificate]
Used for the purpose of testing SSL communications,
but otherwise not normally used.
(8) [Backup]
Click [Exec] to perform a backup of the certificates
and private key. This operation can only be performed
via SSL communications.
(9) [Restore]
Installs the certificates and private key from
backup. Click [Browse] to select the backup file,
then click [Exec]. This operation can only be
performed via SSL communications, and will take
effect after rebooting.
Encrypted Communications
(1) [SSL Communications]
Set SSL communications to [Disable] or [Enable]. The
setting will take effect after rebooting.
However, if no certificate is installed, SSL
communications cannot be changed to [Enable].
Note
• It may take a few minutes to generate an SSL key.
• If SSL communications are used, video transmission
performance drops.
• Depending on the type of the certificate being installed on the
camera, a dialog box may appear indicating that the web
browser has accepted the certificate and a connection can be
made.
If the dialog box does not appear, register the CA certificate in
the web browser.

Canon VB-H43 Specifications

General

Type	IP security camera
PTZ control	Yes
Processor model	Canon DIGIC DV III
Placement supported	Indoor
Light exposure modes	Aperture priority AE, Auto, Manual, Shutter priority AE
Connectivity technology	Wired
Form factor	Dome
Mounting type	Ceiling
Product color	White
Total megapixels	2.1 MP
Maximum resolution	1920 x 1080 pixels
Supported video modes	1080p, 720p
Video formats supported	H.264, M-JPEG
Supported graphics resolutions	320 x 240, 960 x 540, 1280 x 960, 1280 x 720 (HD 720), 1920 x 1080 (HD 1080), 640 x 480 (VGA)
Pan range	-170 - 170 °
White balance	Auto, Daylight, Fluorescent, Lamp, Manual
Tilt angle range	-90 - 10 °
Camera shutter speed	0.0000625 - 1 s
Minimum illumination	0.001 lx
Sensor type	CMOS
Optical sensor size	1/3 \
Digital zoom	12 x
Optical zoom	20 x
Focus adjustment	1.6 - 3.5
Focal length range	4.7 - 94 mm
Security algorithms	EAP-MD5, EAP-TLS, EAP-TTLS, SSL/TLS
Password protection type	User
Built-in HDD	No
Internal memory	5 MB
Compatible memory cards	SD, SDHC, SDXC
Cabling technology	10/100Base-T(X)
Supported network protocols	TCP/IP, UDP, HTTP, FTP, SNMP (MIB2), SMTP (Client), DHCP (Client), DNS (Client), ARP, ICMP, POP3, NTP, SMTP authentication, RTSP, WV-HTTP (Canon proprietary), ONVIF
Compliance industry standards	802.3af PoE
Interface	RJ-45
Ethernet LAN (RJ-45) ports	1
Audio system	2-way
Built-in microphone	-
AC input voltage	24 V
Power source type	PoE
Power consumption (max)	9.2 W
Operating temperature (T-T)	-10 - 50 °C
Operating relative humidity (H-H)	5 - 85 %

Weight and Dimensions

Width	132 mm
Height	155 mm
Weight	1140 g
