Canon VB-H43 User Manual

8
Maintenance
Turn off the power before cleaning the camera.
 Cleaning of Exterior
1 Dampen a soft cloth with water or diluted neutral
detergent and wipe away the grime gently.
2 Wipe with a dry cloth.
 Cleaning of Lens
Use a commercial lens cleaner to remove grime on the
lens surface.
• Auto focus may not work properly if the
lens surface is dusty or dirty.
• Be aware that scratches on the lens surface may result
in poor image capture.
 Cleaning of Front Cover, Dome Case, or
Dome Housing
Grime on any of the parts listed below will reduce image
quality, so periodic cleaning is required.
Dome (when using the separately sold
indoor dome housing)
Dome case
Front cover
If the surface of the above part cannot be cleaned well,
remove it following the steps below to clean it more
thoroughly.
1 Remove the front cover, dome case, or dome.
See steps in “Installing the Camera” in the “Installation
Guide” included with the indoor dome housing and
remove the dome.
See steps in “Installing the Camera” in the “Installation
Guide” included with the camera to remove the dome
case.
See “Using Camera Housing” in the “Installation Guide”
included with the camera to remove the front cover.
2 Dampen a soft cloth with water or diluted neutral
detergent and wipe away the grime gently.
3 Wipe with a dry cloth.
4 Reattach the front cover, dome case or dome to its
original position.
Disposing of the Camera
Dispose of the camera in accordance with local laws and
regulations.

Canon VB-H43 Specifications

General

Type	IP security camera
PTZ control	Yes
Processor model	Canon DIGIC DV III
Placement supported	Indoor
Light exposure modes	Aperture priority AE, Auto, Manual, Shutter priority AE
Connectivity technology	Wired
Form factor	Dome
Mounting type	Ceiling
Product color	White
Total megapixels	2.1 MP
Maximum resolution	1920 x 1080 pixels
Supported video modes	1080p, 720p
Video formats supported	H.264, M-JPEG
Supported graphics resolutions	320 x 240, 960 x 540, 1280 x 960, 1280 x 720 (HD 720), 1920 x 1080 (HD 1080), 640 x 480 (VGA)
Pan range	-170 - 170 °
White balance	Auto, Daylight, Fluorescent, Lamp, Manual
Tilt angle range	-90 - 10 °
Camera shutter speed	0.0000625 - 1 s
Minimum illumination	0.001 lx
Sensor type	CMOS
Optical sensor size	1/3 \
Digital zoom	12 x
Optical zoom	20 x
Focus adjustment	1.6 - 3.5
Focal length range	4.7 - 94 mm
Security algorithms	EAP-MD5, EAP-TLS, EAP-TTLS, SSL/TLS
Password protection type	User
Built-in HDD	No
Internal memory	5 MB
Compatible memory cards	SD, SDHC, SDXC
Cabling technology	10/100Base-T(X)
Supported network protocols	TCP/IP, UDP, HTTP, FTP, SNMP (MIB2), SMTP (Client), DHCP (Client), DNS (Client), ARP, ICMP, POP3, NTP, SMTP authentication, RTSP, WV-HTTP (Canon proprietary), ONVIF
Compliance industry standards	802.3af PoE
Interface	RJ-45
Ethernet LAN (RJ-45) ports	1
Audio system	2-way
Built-in microphone	-
AC input voltage	24 V
Power source type	PoE
Power consumption (max)	9.2 W
Operating temperature (T-T)	-10 - 50 °C
Operating relative humidity (H-H)	5 - 85 %

Weight and Dimensions

Width	132 mm
Height	155 mm
Weight	1140 g
