Canon VIXIA HF S10 User Manual

Video  81
NOTES
• When the audio level meter reaches the red point (0 dB mark), the
sound may be distorted.
• If the audio level is too high and the sound gets distorted, activate the
microphone attenuator ( 143).
• We recommend using headphones ( 81) to check the sound level
while adjusting the audio recording level or when the microphone atten-
uator is activated.
• This function can also be assigned to the custom key/dial ( 85). In
that case, the audio level adjustment bar appears in white.
Using Headphones
Use headphones for playback or to check the audio level while record-
ing. The headphones are connected to the AV OUT/ terminal, which
is used for both the headphones and the audio/video output. Before
connecting the headphones, follow the procedure below to change the
function of the terminal from AV output to (headphones) output.
* Headphones can be used also in mode but the function of the terminal can-
not be changed in that mode.
[ Menu] [AV/Headphones]
[Headphones]
appears.
(33)
*
FUNC.
FUNC.
COPY

Canon VIXIA HF S10 Specifications

General

Filter size	58 mm
Digital zoom	200 x
Optical zoom	10 x
Image stabilizer	Yes
Focal length range	6.4 - 64 mm
Focal length (35mm film equivalent)	43.5 - 435 mm
Sensor type	CMOS
Total megapixels	8.59 MP
Optical sensor size	1/2.6 \
Optical sensor resolution	8020000 pixels
Effective megapixels (movie)	6010000 MP
Focus	TTL
Interface	USB 2.0
Video out	1
Resolution	3264 x 2456 pixels
Display diagonal	2.7 \
Macro focusing range	0.1 m
Normal focusing range	1 m
Video formats supported	H.264
Maximum video resolution	1920 x 1080 pixels
Analog signal format system	NTSC
Flash memory	32 GB
Camcorder tape type	HDV
Compatible memory cards	SD, SDHC
Minimum illumination	0.3 lx
Shutter speed (photo)	1/500 s
Shutter speed (video)	1/2000 s
Product color	Black
Battery type	BP-807
Video recording time	12.25 h
Bundled software	Pixela ImageMixer 3SE

Weight and Dimensions

Depth	136 mm
Width	70 mm
Height	69 mm
Weight	500 g
