Casio CE-250 Service Manual

PARTS PRICE LIST
N Item Code No. Parts Name Specification
Price code
Rank
PCR-365A CE-250 CE-200
1. Main PCB block
N 1 10015651 PCB ASSY SET/E248-1, E248-E2-1 E140345*1 1 1 1
DX
A
and E248-E2-2
F1 30007777 FUSE 230.600 1 1 1
AE
A
IC1 21207349 IC/LINEAR TL431CLPB 1 1 1
AG
A
IC10 21120837 IC/RESET S-80845ANY-Z 1 1 1
AB
A
IC11,13 21051218 IC/MOS TC74HC08AP 2 2 2
AC
A
IC12,14,15 21051008 IC/MOS TC74HC00AP 3 3 3
AC
A
IC18 21010189 IC/MOS TC74HC138AP 1 1 1
AE
A
IC2 20061326 LSI UPD16312GB-3B4 1 1 1
AX
A
IC3 21120840 IC/RESET S-80819ANY-Z 1 1 1
AB
A
N IC4 10024616 LSI UPD78052GC-159-3B9 1 1 1
CE
A
IC6 21051169 IC/MOS TC74HC373AP 1 1 1
AG
A
IC7 20061648 LSI M27C512-10/12F1 1 1 1
BD
A
IC8 20061701 LSI TC55257DPL-70L/85L 1 1 1
AT
A
IC9,16,17 21120035 IC/MOS TC74HC367AP 3 3 3
AF
A
X1 25203445 OSCILLATOR/CRYSTAL C-002RX(M90-76) 1 1 1
AD
A
X2 24088261 LOCK/CERAMIC CST5.00MGW 1 1 1
AD
A
D1,D28,D32,D33 23153128 DIODE 1SR35-400AT-82 4 4 4
AA
B
D29,D30 23153134 DIODE SB10-04A3-BT 2 2 2
AB
B
D31 23153095 DIODE/SHOTTKY RB721Q-40T-77 1 1 1
AA
B
D34 23153131 DIODE 1SS118TD 1 1 1
AA
B
D35 23902828 DIODE RB441Q-40T-77 1 1 1
AA
B
D3-D5,D7-D26 23153132 DIODE 1SS133T-77 23 23 23
AA
B
D6 23153133 DIODE 1SS244T-77 1 1 1
AA
B
DB1
23152857 BRIDGE/DIODE S2VB20
1 1 1
AF
B
DCS1
30007623 CONVERTER/DC-DC DCS-298
1 1 1
AR
B
N FB1,3,4
30006335
INDUCTOR
BL02RN2-R62-001
3 3 3
AB
B
Q1
22501554
TRANSISTOR
2SD1063(R,S)
1 1 1
AN
B
Q10,11,14,16,18,20,
22501635 TRANSISTOR DTC143ZSA-TP 13 13 13 AA B
Q12,13,15,17,19,21,
23,25,27,30
22305261 TRANSISTOR 2SD965(P.Q.R)-TA 10 10 10 AB B
Q2,5,31,36
22501330
TRANSISTOR
2SC1740S(QRSE)TP
4 4 4
AA
B
Q29
22107186
TRANSISTOR
2SB926(T,U)-AA
1 1 1
AC
B
Q3
22501309
TRANSISTOR
2SD1804(T)
1 1 1
AF
B
N Q35
22501633
TRANSISTOR
2SA1015(0.Y.GR)-TP
1 1 1
AA
B
Q4
22501323
TRANSISTOR
2SA933AS(QRS)TP
1 1 1
AA
B
Q6
22304135
TRANSISTOR
2SD1853-AA
1 1 1
AC
B
Q8
22303902
TRANSISTOR
2SD1111-AA
1 1 1
AC
B
ZD1
23152661 DIODE/ZENER RD36EB1-T1
1 1 1
AA
B
ZD2
23153112 DIODE/ZENER RD33EB1-T1
1 1 1
AA
B
ZD3
23153109 DIODE/ZENER RD5.6EB2-T1
1 1 1
AA
B
ZD5-12
23152836 DIODE/ZENER RD20EB2-T1
8 8 8
AA
B
BZ1
32402089 BUZZER PKM22EPT-2001
1 1 1
AE
C
C1
28072658 CAPACITOR/ELECTROLYTIC RE3-25V472M
1 1 1
AL
C
C14,34
28073099 CAPACITOR/ELECTROLYTIC RE2-10V470MMA-T2
2 2 2
AA
C
C19
28073582 CAPACITOR/ELECTROLYTIC RE3-6.3V472M
1 1 1
AE
C
C3,18
28072294 CAPACITOR/ELECTROLYTIC RE3-10V471M-T2
2 2 2
AB
C
C35
28072707 CAPACITOR/ELECTROLYTIC RE3-16V101M-T2
1 1 1
AA
C
C44
28072847 CAPACITOR/ELECTROLYTIC RE2-16V100MMA-T2
1 1 1
AA
C
C7
28073575 CAPACITOR/ELECTROLYTIC RE2-50V101M-T2
1 1 1
AB
C
C7,9,10
28451134 CAPACITOR/MODULE CNB4X101K
3 3 3
AC
C
CA1
28450056 CAPACITOR/MODULE CNB6X221K
1 1 1
AC
C
CA2
28450182 CAPACITOR/MODULE CNB6X101K
1 1 1
AC
C
CA3-6,8,11
28450168 CAPACITOR/MODULE CNB8X101K
6 6 6
AD
C
CN1
35802371 CONNECTOR B4P-VH
1 1 1
AB
C
CN10
35107631 CONNECTOR HBLB20S-1J
1 1 1
AE
C
CN2
35003355 CONNECTOR IL-G-3P-S3T2-E
1 1 1
AA
C
CN4,11
35015404 CONNECTOR 52045-2445
2 2 2
AD
C
CN5
35016244 CONNECTOR B2B-PH-K-S
1 1 1
AA
C
CN8
35005845 CONNECTOR B3B-PH-K-S
1 1 1
AA
C
FT1
28073619 FILTER/EMI DSS310H-55B222M250
1 1 1
AB
C
IC7
36350024 SOCKET/IC DILB28P-8JK
1 1 1
AC
C
RA1
26522274 RESISTOR/CHIP NETWORK RGLD4X222J
1 1 1
AA
C
RA2,6,7,11
26522288 RESISTOR/CHIP NETWORK RGLD6X563J
4 4 4
AA
C
RA3-5,8
26521350 RESISTOR/CHIP NETWORK RGLD8X563J
4 4 4
AB
C
RA9,10,12
26522281 RESISTOR/CHIP NETWORK RGLD4X563J
3 3 3
AA
C
C10,11
CAPACITOR/CERAMIC RT-HE50TKYB102K
2 2 2
NOT SUPPLY
X
C12
CAPACITOR/CERAMIC RT-HE40TKCH120J
1 1 1
NOT SUPPLY
X
C13
CAPACITOR/CERAMIC RT-HE40TKCH150J
1 1 1
NOT SUPPLY
X
Q'ty
- 45 -
