Casio CE-250 Service Manual

N Item Code No. Parts Name Specification
Price code
Rank
PCR-365A CE-250 CE-200
Q'ty
C16,17,20,26,31,33,
36,50-54
CAPACITOR/CERAMIC RT-DSTB90TKYR104K 12 12 12 NOT SUPPLY X
C24,43
CAPACITOR/CERAMIC RT-HE12TKYB103K
2 2 2
NOT SUPPLY
X
C28
CAPACITOR/CERAMIC RT-HE40TKYB221K
1 1 1
NOT SUPPLY
X
C5,15
CAPACITOR/CERAMIC RT-HE60TKYB222K
2 2 2
NOT SUPPLY
X
C6
CAPACITOR/CERAMIC RT-HE40TKYB471K
1 1 1
NOT SUPPLY
X
C8,29,30,37
CAPACITOR/FILM AMZV0050K1040200
4 4 4
NOT SUPPLY
X
C9,21-23,25,27,40-
42,45-49
CAPACITOR/CERAMIC RT-HE40TKYB101K 14 14 14 NOT SUPPLY X
R1
RESISTOR R-50XT-24J751
1 1 1
NOT SUPPLY
X
R10
RESISTOR R-50XT-24J101
1 1 1
NOT SUPPLY
X
R12
RESISTOR RD1/4WT-24Y201J
1 1 1
NOT SUPPLY
X
R14,35,67,75
RESISTOR RD1/4WT-24Y223J
4 4 4
NOT SUPPLY
X
R15
RESISTOR RD1/4WT-24Y272J
1 1 1
NOT SUPPLY
X
R16,37
RESISTOR RD1/4WT-24Y513J
2 2 2
NOT SUPPLY
X
R18
RESISTOR RD1/4WT-24Y334J
1 1 1
NOT SUPPLY
X
R19
RESISTOR RD1/4WT-24Y684J
1 1 1
NOT SUPPLY
X
R2
RESISTOR RD1/4WT-24Y122G
1 1 1
NOT SUPPLY
X
R22
RESISTOR RD1/4WT-24Y105J
1 1 1
NOT SUPPLY
X
R24
RESISTOR RD1/4WT-24J104J
1 1 1
NOT SUPPLY
X
R25,66
RESISTOR RD1/4WT-24Y472J
2 2 2
NOT SUPPLY
X
R27
RESISTOR RSN1WMG15RJ
1 1 1
NOT SUPPLY
X
R29
RESISTOR RD1/4WT-24Y222J
1 1 1
NOT SUPPLY
X
R3
RESISTOR RD1/4WT-24Y102G
1 1 1
NOT SUPPLY
X
R39,76-79
RESISTOR RD1/4WT-24Y563J
5 5 5
NOT SUPPLY
X
R4
RESISTOR CRH100-FH11J-2R2
1 1 1
NOT SUPPLY
X
R40,61,62,68,73
RESISTOR RD1/4WT-24Y102J
5 5 5
NOT SUPPLY
X
R5
RESISTOR
RD1/4WT-24Y751J 1 1 1
NOT SUPPLY
X
R63,71,72
RESISTOR RD1/4WT-24Y471J
3 3 3
NOT SUPPLY
X
R7,23,32-
34,38,42,43,45,49,5
RESISTOR RD1/4WT-24Y101J 17 17 17 NOT SUPPLY X
R70
RESISTOR RD1/4WT-24Y221J
1 1 1
NOT SUPPLY
X
R8,9,11,17,26,36,41
,44,46-
48,51,52,56,57,60,6
RESISTOR RD1/4WT-24Y103J 18 18 18 NOT SUPPLY X
SCREW 3X8 ZMC-3.....
7 7 7
NOT SUPPLY
X
2. Main Display block
2 PCB ASSY/E248-E2-1 (Order by Main PCB) 1 1 1
NOT SUPPLY
X
DISP1
24088226 TUBE/DISPLAY
SH101MA
1 1 1
BP
B
CUSHION/DISPLAY
E412177-1
2 2 2
NOT SUPPLY
X
CN1
35015404 CONNECTOR
52045-2445
1 1 1
AD
C
N CN2
10030171 CONNECTOR
52806-1210
1 1 1
AC
C
N CN3
10030170 CONNECTOR
52806-1010
1 1 1
AC
C
3
62480508 CABLE/FFC JOINT E E247 E440442-1
1 1 1
AK
C
30008040 CORE/FERRITE SSC-40-12
1 1 1
AF
C
3. Customer Display block
4 PCB ASSY/E248-E2-2 (Order by Main PCB) 1 1 1
NOT SUPPLY
X
DISP1
24088233 TUBE/DISPLAY
SH1019A
1 1 1
BM
B
CUSHION/DISPLAY
E440189-4
2 2 2
NOT SUPPLY
X
N CN1
10030157 CONNECTOR
52807-1210
1 1 1
AA
C
N CN2
35022620 CONNECTOR
52807-1010
1 1 1
AA
C
5
62481476 CABLE/FFC JOINT E E445 E440657-5
1 1 1
AU
C
6
62481475 CABLE/FFC JOINT D E445 E440657-4
1 1 1
AU
C
30008041 CORE/FERRITE SSC-33.5-12
AE
7
62481274 CASE/REAR DISPLAY E240511-1
1 1 1
AY
C
N 8
10027092 PLATE/REAR DISPLAY E240512A-6
1 1 1
AT
B
62481698 PLATE/INSULATION E440781-1
1 1 1
AB
C
4. Button block
9
62213988 CAP/L E210964-1
3 3 3
AB
C
10
62214025 CAP/S E311103-1
42 42 42
AA
C
11
62457250
BUTTON/1
E311792-1
1 1 1
AB
C
12
62457260
BUTTON/2
E311792-2
1 1 1
AB
C
13
62457270
BUTTON/3
E311792-3
1 1 1
AB
C
14
62457280
BUTTON/4
E311792-4
1 1 1
AB
C
15
62457290
BUTTON/6
E311792-5
1 1 1
AB
C
16
62457300
BUTTON/7
E311792-6
1 1 1
AB
C
17
62457310
BUTTON/8
E311792-7
1 1 1
AB
C
18
62457320
BUTTON/9
E311792-8
1 1 1
AB
C
19
62457330
BUTTON/0
E311792-9
1 1 1
AB
C
20
62457340
BUTTON/.
E311792-10
1 1 1
AB
C
- 46 -
