– 13 –
IT-G500
5. HARDWARE TEST / SETTING
5-1. General
In this chapter, how to check the hardware of IT-G500 is explained.
The general fl ow to start up the test program is as follows:
Prepare equipment required.
PC
Obtain the test program Diag_Itg500.zip
(Download from website.)
Unzip Diag_Itg500.zip and copy it to a MicroSD card.
(For both test object IT-G500 and opponent IT-G500)
IT-G500
Install the MicroSD card.
Copy the test program from the MicroSD card to the FlashDisk.
Prepare equipment required.
Remove the MicroSD card.
Start the test program.
Perform Initial Settings
Perform function tests.
Delete the test program from the FlashDisk.

Casio IT-G500 Specifications

General

Type	Handheld bar code reader
Wavelength	650 nm
Sensor type	CMOS
Scanner type	2D
Tilt reading angle	0 - 25 °
Optical sensor resolution	0.25 pixels
Linear (1D) barcodes supported	Codabar, Code 128, Code 32, Code 39, Code 93, EAN-13, EAN-8, MSI
2D (matrix & stacked) barcodes supported	Aztec Code, Data Matrix, MaxiCode, Micro QR Code, MicroPDF417, QR Code
Battery voltage	3.7 V
Power source type	Battery
Battery technology	Lithium
USB version	2.0
Standard interfaces	USB, Bluetooth, Wireless LAN
Connectivity technology	Wireless
Operating temperature (T-T)	-20 - 50 °C
Operating relative humidity (H-H)	10 - 90 %
RAM capacity	512 MB
Keys quantity	22 keys
Product color	Black
LED indicators	Charging, Status
Internal memory	4000 MB
Built-in display	Yes
Housing material	-
Display resolution	480 x 800 pixels
Display technology	LCD/TFT
Processor frequency	1.5 MHz
Protection features	Dust resistant, Water resistant
International Protection (IP) code	IP67

Weight and Dimensions

Depth	22 mm
Width	74 mm
Height	175 mm
Weight	270 g
