– 22 –
IT-G500
5-5. Test Procedures
Y
Continuous Test
No. Operation Test Details
1
Select [0].Continuous Test. (MENU-2) The test is automatically done in the order of
RAM → ROM → EEPROM →ADC sensor.
If OK:
The screen returns to the menu screen.
If any problem:
Press the “ENT” key to return to the menu
screen.
Y
Key-1
NOTE:
Note that the numeric key layout appears on the screen is diff erent from the actual numeric
key layout of IT-G500.
No. Operation Test Details
1
Select [3].Key-1. (MENU-2) The key statuses are displayed. The pressed
key appears inverted on the screen.
Press all keys in any order. When all key
have been successfully pressed, the test
result is judged as OK and the screen returns
to the menu screen.
NOTE:
• When testing the “Power” key, press it for
a while.
• Pressing the “ENT” key twice in the middle
stops the test and returns the screen to
the menu screen. In this case, test result is
judged as Failure.
To Next Page
