– 5 –
2. SPECIFICATION
2-1. System Requirements
MODEL
IT-3100M53E/
M53E2
IT-3100M54E/
M54E2
IT-3100M55E/
M55E2
IT-3100M55U
IT-3100M56E/
M56E2
IT-3100M56U
CPU Marvell
®
PXA255 Application Processor (400 MHz max.)
OS Microsoft
®
Windows
®
CE 5.0 operating system
Memory RAM 128MB
ROM 96MB ROM (user dened: Approx. 30MB)
Display Type 3.5-inch, 2-Way TFT Color LCD
Size
240 × 320 dots
C-MOS Imager Reading 1D Code symbologies
_ _
UPC-A/UPC-E/EAN8 (JAN8)/EAN13 (JAN13)/Codabar (NW-7)/
Code39/Interleaved 2 of 5 (ITF)/MSI/Code93/Code128 (EAN128)/
Code11/IATA/RSS-14 (GS1 DataBar Omnidirectional)/RSS Limited
(GS1 DataBar Limited)/RSS Expanded (GS1 DataBar Expanded)
Reading distance
_ _
Within approximately 40 mm~410 mm (1
9
/
16
" to 16
1
/
8
")
Reading stacked 2D Code
symbologies (Stacked)
_ _
PDF417/Micro PDF/CODE49/Composite/Codablock F/TLC39/RSS-14
Omnidirectional Stacked (GS1 DataBar Omnidirectional Stacked)/RSS
Expanded Stacked (GS1 DataBar Expanded Stacked)/RSS-14 Stacked
(GS1 DataBar Stacked)
Reading distance
_ _
Within approximately 50 mm to 250 mm (11
5
/
16
" to 9
13
/
16
")
Reading Matrix 2D Code
symbologies (Matrix)
_ _
Aztec, Data Matrix, Maxicode, QR Code
Reading distance
_ _
Within approximately 60 mm to 150 mm (2
3
/
8
" to 5
15
/
16
")
IR
Communication
Interface Compatible with IrDA Ver. 1.1
Synchronization Start/stop synchronous, frame synchronization
Transfer Rate Up to 4 Mbps (max.)
Serial Interface Interface 8-pin
_ _ _ _
Synchronization Start/stop synchronous
_ _ _ _
Transfer Rate 300 bps to 115.2 Kbps
_ _ _ _
14-pin Serial
Interface
Interface 14-pin
Synchronization Start/stop synchronous
Transfer Rate 300 bps to 115.2 Kbps
* Wake on function available
Bluetooth
Communication
Protocol Bluetooth
®
Specication Ver.1.2 : (M53E/M54E/M55E/M55U/M56E/M56U)
Bluetooth
®
Specication Ver.2.0 : (M53E2/M54E2/M55E2/M56E2)
Range Approximately 3 m (depends on radio wave conditions and environment)
Output 3 dBm max. (PowerClass2)
* Wake on function available
To Next Page
