— 93 —
12. PARTS LIST
Notes: 1. The numbers in the item column correspond to the same numbers in exploded view.
2. MARKS:
Q: Quantity used per unit
R: Rank A: Essential
B: Stock recommended
C: Less recommended
X: No stock recommended
3. Prices and Specications are subject to change without prior notice.
1 IT-3100M53E 3 IT-3100M54E 5 IT-3100M55E 7 IT-3100M55U 9 IT-3100M56E2
2 IT-3100M53E2 4 IT-3100M54E2 6 IT-3100M55E2 8 IT-3100M56E 10 IT-3100M56U
UPPER CASE ASSY
1 10315786 CASE ASSY/UPPER RJC501567*003 TK
2 10317410 PLATE/GUIDANCE RJC501190-004V02 1 1
3 10306538 BUTTON/POWER RJC504032*001V01 1 1
4 10288955 TAPE/CN RJC503687-001V01 1 1
5 10147469 SPEAKER MS-1578 1 1
6 10255283 PCB ASSY/POWER KEY RJC503044*001V01TK 1 1
7 10306536 BUTTON SET/KEY RJC502552*003V01 1 1
8 10246156 SCREW RJC502686-003V01 7777777777X
9 10240972 PCB ASSY/KEY RJC502476E101V01TK 1 1
111 10318861 SHEET/PW/INS RJC504141-001V01 1 1
112 10318862 SUPPORT/PW RJC504143-001V01 1 1
113 10318864 TAPE/SUPPORT RJC504144-001V01 1 1
114 10246158 SCREW RJC502609-003V01 2222222222X
Item#1 CASE ASSY/UPPER
1-1 10161413 PROTECTION SHEET/CUTTER RJC501461-001V03 1 1
1-2 10160416 CUTTER/PAPER RJC501206-001V02 1 1
1-3 10160417 CUSHION/CUTTER RJC501207-001V02 1 1
1-4 10190460 TAPE/SEMICON RJC501761-001V01 1 1
Item#6 PCB ASSY/POWER KEY
6-1 10147468 FFC CABLE/POWR KEY PCB RJC501251-001V01 1 1
6-2 10165058 SHEET/SHIELD RJC501617-001V01 1 1
Item#9 PCB ASSY/KEY
9-1 10147540 FFC CABLE/KEY PCB RJC501254-001V01 1 1
9-2 10165056 SHEET/SHIELD RJC501614-001V01 1 1
SW1 10147475 SWITCH SPPB630101 1 1
N Item Part No. Part Name Descriptions R
QUANTITY
To Next Page
